Baileigh Semi-Automatic Column Coldsaw CS-C425SA 1002633 Applications
- Structural steel fabrication facilities.
- Industrial machine and fabrication shops.
- Production cutting of pipe, tubing, and solid stock.
- Automotive, aerospace, and equipment manufacturing.
- Metal service centers and production facilities.
- Industrial maintenance and repair operations.
- Heavy-duty manufacturing and fabrication environments.
- High-volume cutting applications requiring repeatable accuracy.
The Baileigh Semi-Automatic Column Coldsaw CS-C425SA 1002633 combines industrial durability, precision cutting, and semi-automatic productivity to deliver clean, repeatable cuts with minimal secondary finishing.
Baileigh Semi-Automatic Column Coldsaw CS-C425SA 1002633 Specifications
| Model | CS-C425SA |
|---|---|
| Manufacturer | Baileigh Industrial |
| Product Number | 1002633 |
| Machine Type | Semi-Automatic Column Cold Saw |
| Maximum Blade Diameter | 17 in. |
| Motor | 5 HP |
| Input Power | 220V Three Phase |
| Blade Speeds | 35, 60, 70, and 120 RPM |
| Maximum Round Tube Capacity | 4.92 in. |
| Maximum Round Solid Capacity | 2.75 in. |
| Miter Range | 45° Left / 60° Right |
| Vise Style | Hydraulic Self-Centering Vise |
| Coolant System | Flood Coolant Pump |
| Construction | Vertical Column with Hardened Slideway Tracks |
| Net Weight | 1,870 lbs. |
| Gross Weight | 1,870 lbs. |
| Warranty | 1 Year |
| UPC | 19907315438 |
Baileigh Semi-Automatic Column Coldsaw CS-C425SA 1002633 Performance & Construction
- Powerful 5 HP industrial motor delivers dependable cutting performance for demanding production environments.
- 220V three-phase electrical operation provides consistent power for continuous industrial fabrication.
- 17-inch maximum blade capacity enables cutting of larger structural materials, pipe, tubing, and solid stock.
- Four selectable blade speeds of 35, 60, 70, and 120 RPM allow operators to optimize cutting performance for different materials and thicknesses.
- Vertical column design with hardened slideway tracks maintains precise blade alignment while minimizing vibration for consistently accurate cuts.
- Maximum 4.92-inch round tube capacity accommodates large-diameter tubing and pipe commonly used in industrial fabrication.
- Maximum 2.75-inch round solid capacity provides excellent versatility for cutting solid bar stock.
- Hydraulic self-centering vise securely clamps workpieces while automatically centering material for repeatable cutting accuracy.
- 45° left and 60° right miter capability allows accurate angle cutting for frames, structural components, and custom fabrication projects.
- Semi-automatic operating cycle increases production efficiency while reducing operator fatigue during repetitive cutting operations.
- Flood coolant system continuously lubricates the blade, removes chips, extends blade life, and produces cleaner, burr-free cuts.
- Metered stop rod supports repeatable production cuts for improved workflow and consistent part lengths.
- Heavy-duty industrial construction is engineered for long service life in demanding fabrication and manufacturing facilities.
- Supported by Baileigh's 1-year warranty and lifetime technical support for dependable long-term ownership.
Why Choose the Baileigh Semi-Automatic Column Coldsaw CS-C425SA 1002633
- Industrial-grade semi-automatic cold saw designed for production cutting.
- Powerful 5 HP three-phase motor delivers reliable performance.
- Four blade speeds optimize cutting for multiple material types.
- Large 17-inch blade handles demanding structural cutting applications.
- Hydraulic self-centering vise improves cutting accuracy and repeatability.
- Vertical column design enhances rigidity and precision.
- Flood coolant system extends blade life while producing cleaner cuts.
- 4.92-inch round tube capacity accommodates large fabrication materials.
- 45° left and 60° right miter capability increases cutting versatility.
- Backed by Baileigh's 1-year warranty and lifetime technical support.
The Baileigh Semi-Automatic Column Coldsaw CS-C425SA 1002633 is a heavy-duty production cold saw built for professionals who demand maximum precision, durability, and throughput. Combining a rigid vertical column design, powerful 5 HP motor, four-speed operation, hydraulic self-centering vise, and semi-automatic cutting cycle, this industrial machine delivers clean, repeatable, burr-free cuts while maximizing efficiency in demanding fabrication and manufacturing environments.
