Castaly 12" Radial Arm Saw RS-612 Applications
- Cabinet and furniture workshops
- Precision crosscutting of boards and panels
- Miter and bevel cutting for frames and trim
- Job shop and custom woodworking applications
- Light production environments requiring accuracy and repeatability
An ideal solution for workshops needing reliable crosscut performance in a compact footprint.
Castaly 12" Radial Arm Saw RS-612 Specifications
| Model | RS-612 |
|---|---|
| Motor | 2 HP, 1 Phase, 110V |
| Motor Speed | 2900 RPM |
| No. of Head Travel Bearings | 4 |
| Spindle Diameter | 1" |
| Saw Blade Diameter | 10" – 12" |
| Max. Trimming Width | 27" |
| Max. Depth of Cut | 3-1/8" |
| Max. Cross Cut Length | 16-1/2" |
| Table Size (L × W) | 25-1/2" × 31-1/2" |
| Head Swiveling (Horizontal) | 0° – 180° |
| Head Tilting (Vertical) | 0° – 90° |
| Machine Size | 31-1/2" × 25-1/2" × 43-1/4" |
| Net Weight | 330 lbs |
| Gross Weight | 380 lbs |
Castaly 12" Radial Arm Saw RS-612 Performance & Construction
- Integrated laser guide projects a straight cutting line for improved accuracy and faster material alignment.
- Hardened and precision-ground rail ensures maximum wear resistance and long-term slide accuracy.
- Ball-bearing head travel system provides smooth, controlled, and effortless movement.
- One-piece cast iron arm enhances rigidity and reduces vibration during operation.
- High-performance self-braking motor improves operator safety by reducing blade coast time.
- Quick position stops at 45° (left and right) for efficient and repeatable angle settings.
- Full swivel (0°–180°) and tilt (0°–90°) allow versatile cutting configurations.
- Safety blade guard protects the operator during cutting operations.
- Anti-kickback attachment included for improved material control and enhanced safety.
- Overload protection switch prevents motor damage during demanding cuts.
- Heavy sheet metal stand provides stable support and long-term structural durability.
Why Choose the Castaly 12" Radial Arm Saw RS-612
- Reliable 2 HP motor suitable for single-phase shop environments.
- Laser-guided cutting accuracy for improved efficiency.
- Compact size with heavy-duty 330 lb construction.
- Smooth sliding action with precision-ground rail system.
- Comprehensive safety features including self-braking motor and overload protection.
The Castaly 12" Radial Arm Saw RS-612 delivers precision, safety, and industrial-grade durability in a compact and efficient design—making it an excellent choice for professional woodworking shops and custom fabrication environments.
