Baileigh 18-Inch Automatic Horizontal Bandsaw, 220V 3Ph (BS-24A) Applications
- Production fabrication and metalworking facilities.
- Structural steel fabrication shops.
- Steel warehouses and service centers.
- Industrial manufacturing operations requiring automatic cutting.
- Machine shops processing round, square, and rectangular stock.
- Pipe, tubing, channel, angle iron, and heavy structural material cutting.
- Batch production where repeatable precision and productivity are essential.
Designed for manufacturers seeking fully automatic cutting with high production output, consistent accuracy, and minimal operator involvement.
Baileigh 18-Inch Automatic Horizontal Bandsaw, 220V 3Ph (BS-24A) Specifications
| Model | BS-24A |
|---|---|
| Product Number | 1001374 |
| Motor | 5 HP Delta® Inverter-Driven Motor |
| Power Requirement | 220V Three Phase |
| Round Cutting Capacity (90°) | 18 in. |
| Rectangular Cutting Capacity (90°) | 24 in. × 15 in. |
| Notch Capacity | 18 in. OD |
| Blade Width | 1.5 in. |
| Blade Speed | 65–279 SFPM Variable Speed |
| Blade Guide | Carbide x Roller Guides |
| Miter Angle Range | 0°–45° |
| Miter Adjustment | Swivel Head |
| Feed System | Automatic Hydraulic Feed |
| Descent Control | Pressure Assist Hydraulic |
| Material Feed | Hydraulic |
| Material Clamping | Hydraulic Bundling Clamp |
| Chip Removal | Hydraulic Auger |
| Return | Hydraulic |
| Load Capacity | 3,960 lb |
| Machine Weight | 3,900 lb |
| UPC | 731325397192 |
Baileigh 18-Inch Automatic Horizontal Bandsaw, 220V 3Ph (BS-24A) Performance & Construction
- Powerful 5 HP Delta® inverter-driven motor provides consistent torque and dependable performance for demanding industrial cutting applications.
- Fully automatic cutting cycle controls material feeding, hydraulic clamping, blade descent, cutting, and return automatically, increasing production while reducing operator fatigue.
- Variable blade speed from 65 to 279 SFPM allows optimization for carbon steel, stainless steel, alloy steel, and numerous other ferrous materials while extending blade life.
- Hydraulic feed and pressure-assisted descent control produce smooth, controlled cutting pressure for cleaner finishes and improved cutting accuracy.
- Hydraulic material clamping system securely holds workpieces throughout the cutting cycle to maintain repeatable dimensional accuracy.
- Heavy-duty welded steel frame with cast-iron bow construction minimizes vibration and deflection, ensuring excellent cutting precision during continuous production.
- Carbide roller blade guides improve blade stability, reduce wear, and enhance straight cutting performance on large workpieces.
- Integrated flood coolant system reduces blade heat, improves cut quality, and significantly extends blade service life during prolonged operation.
- Hydraulic chip auger efficiently removes metal chips from the cutting area to maintain productivity and reduce cleanup time.
- Swivel-head mitering capability from 0° to 45° allows angle cutting without repositioning long stock, improving workflow and production efficiency.
- Large 3,960 lb load capacity accommodates substantial material bundles and oversized workpieces commonly found in industrial fabrication.
Baileigh 18-Inch Automatic Horizontal Bandsaw, 220V 3Ph (BS-24A) Features & Benefits
- 18-inch round cutting capacity for heavy industrial stock.
- 24" × 15" rectangular cutting capacity for structural material.
- Automatic hydraulic feed, clamp, and cutting cycles increase production throughput.
- Variable speed operation for improved blade performance across different metals.
- Hydraulic pressure-assisted descent ensures smooth, controlled cutting.
- Carbide roller blade guides improve accuracy and blade longevity.
- Integrated hydraulic chip auger maintains a cleaner cutting environment.
- Swivel-head miter capability up to 45° increases cutting flexibility.
- Flood coolant system improves finish quality while extending blade life.
- Heavy-duty industrial construction built for continuous production environments.
- Supported by Baileigh's 1-Year Parts Warranty and Lifetime Technical Support.
Why Choose the Baileigh 18-Inch Automatic Horizontal Bandsaw, 220V 3Ph (BS-24A)
- Designed specifically for high-volume industrial metal cutting.
- Large cutting capacities handle structural steel, tubing, pipe, and solid stock.
- Fully automatic hydraulic operation reduces labor while increasing production efficiency.
- Heavy-duty construction delivers exceptional accuracy, durability, and long service life.
- Variable speed cutting and hydraulic controls maximize blade performance and cut quality.
- Industrial-grade design backed by Baileigh's trusted technical support and warranty.
The Baileigh 18-Inch Automatic Horizontal Bandsaw, 220V 3Ph (BS-24A) is a production-ready automatic bandsaw engineered for fabricators and manufacturers who demand precision, reliability, and maximum throughput. Combining powerful hydraulic automation, a 5 HP inverter-driven motor, variable blade speeds, heavy-duty construction, and large cutting capacities, the BS-24A delivers dependable industrial performance for years of continuous metal cutting.
