OMGA Stop 13 - RH Programmable Stop/Positioner System Applications
- Automated woodworking production systems
- Mitre saw and double mitre saw positioning applications
- Up-cut saw and radial arm saw automation
- Table saw and drilling station positioning systems
- Picture frame manufacturing operations
- Plastic fabrication and metalworking production
- Repetitive cutting and material positioning tasks
- Industrial manufacturing cells requiring programmable stop systems
The OMGA Stop 13 - RH Programmable Stop/Positioner System is ideal for manufacturers seeking improved positioning accuracy, increased production efficiency, and repeatable programmable material processing.
OMGA Stop 13 - RH Programmable Stop/Positioner System Specifications
| Model | OMGA Stop 13 - RH |
|---|---|
| Machine Type | Programmable Stop/Positioner System |
| Usable Traverse | 13'1" |
| Motor Type | Brushless Motor |
| Brushless Motor Power | 0.66 kW (0.9 HP) |
| Maximum Traversing Speed | 200 FPM |
| Positioning Accuracy | ±0.004" |
| Software Versions Included | Pusher Basic, Advanced Pusher, and Picture Frame |
| Maximum Number of Programs | 500 |
| Connection Ports | 2 x USB, 2 x RS 232, and 1 x RJ45 |
| Removable Media Support | USB Port and Ethernet Port |
| Measurement Units | Millimeters and Inches |
| Input Formats | Fractional and Decimal |
| Controller Interface | Touch-Screen Controller |
| System Orientation | Right Hand Configuration |
OMGA Stop 13 - RH Programmable Stop/Positioner System Features & Performance
- Programmable numerical positioning system improves cutting consistency and reduces manual setup time.
- 13'1" of usable traverse supports accurate positioning and handling of long materials during production operations.
- High-speed traversing capability of up to 200 FPM improves productivity and workflow efficiency.
- Industrial brushless motor drive system delivers smooth positioning movement with reduced maintenance requirements.
- Precision positioning accuracy of ±0.004" ensures highly repeatable production results.
- Integrated touchscreen controller simplifies machine operation, programming, and production setup.
- Complete software package included featuring Pusher Basic, Advanced Pusher, and Picture Frame applications with no additional software purchase required.
- Large program storage capacity allows operators to save up to 500 production programs for quick recall and repeat production.
- Compatible with multiple industrial machine types including saws, drills, and cutting systems used in woodworking, plastics, and metalworking industries.
- Supports inch and metric operation for flexible international production compatibility.
- Fractional and decimal programming input provides additional flexibility for operators and production environments.
- Multilingual touchscreen interface available in multiple languages for global manufacturing operations.
- Advanced diagnostic capabilities assist operators with troubleshooting and minimize unnecessary downtime.
- Multiple communication ports including USB, RS 232, and RJ45 Ethernet connectivity allow interfacing with computers, barcode readers, printers, USB memory devices, and production networks.
- Optional Interlink Kits available for advanced automation integration and machine connectivity.
- Eliminates repetitive tape measuring while improving production accuracy and reducing operator error.
Why Choose the OMGA Stop 13 - RH Programmable Stop/Positioner System
- Improves positioning accuracy and repeatability in production environments.
- Converts manual machinery into efficient programmable manufacturing systems.
- Compatible with woodworking, plastics, and metalworking applications.
- High-speed positioning improves workflow productivity.
- Advanced software and touchscreen controls simplify machine operation.
- Extensive connectivity supports integration with modern manufacturing systems.
- Large memory capacity allows fast program recall and efficient production scheduling.
- Industrial-grade construction designed for demanding daily manufacturing operations.
The OMGA Stop 13 - RH Programmable Stop/Positioner System combines programmable positioning accuracy, intelligent touchscreen control, and industrial automation performance into a highly effective solution for repetitive cutting and material processing applications.
