Laguna SuperMax 13″ Combination Brush/Drum Sander SUPMX-91067 Applications
- Profile sanding for mouldings and detailed wood components
- Raw wood sanding and surface preparation
- Between-coat sanding for stain, sealer, and primer
- Cleaning and light distressing of wood surfaces
- Fine finishing for cabinetry, furniture, and millwork
Perfect for small to mid-sized shops that need flexible finishing capabilities in a compact footprint.
Laguna SuperMax 13″ Combination Brush/Drum Sander SUPMX-91067 Specifications
| Model | 13″ Combination Brush/Drum Sander |
|---|---|
| Part Number | SUPMX-91067 |
| Motor | 1.75 HP, 110V |
| Sanding Width | 13" |
| Maximum Thickness | 4" |
| Minimum Thickness | 1/32" |
| Minimum Length | 9" |
| Drum Size | 5" × 13" extruded aluminum (optional) |
| Brush Diameter | 6" – 8" |
| Brush Speed | 400 – 1200 RPM (variable) |
| Conveyor Speed | 0 – 10 FPM variable |
| Conveyor Motor | 43 in-lb torque, variable DC motor |
| Dust Collection | 1 × 4" port (600 CFM recommended) |
| Dimensions (W × L × H) | 42" × 35" × 44" |
| Power Requirements | 110V, 20 Amp |
| Shipping Weight | Approx. 300 lbs |
| Shipping Dimensions | 34-1/2" × 45-1/2" × 46-1/2" |
| Electrical | NEMA 5-15P Plug |
Laguna SuperMax 13″ Combination Brush/Drum Sander SUPMX-91067 Performance & Construction
- Combination sanding capability allows both brush sanding and optional drum sanding in one machine.
- Infinitely variable brush and conveyor speeds provide precise control over finish quality.
- Quick-change brush system enables fast switching between applications and abrasive types.
- Adjustable tension rollers prevent stock slippage and ensure consistent feed.
- Reinforced steel conveyor bed with durable poly belt for long-term reliability.
- Precision height adjustment ensures accurate and repeatable sanding results.
- Bristle contact gauge included for consistent brush engagement.
- Large diameter brush design increases aggressiveness, improves penetration, and extends brush life.
Laguna SuperMax 13″ Combination Brush/Drum Sander SUPMX-91067 Productivity Benefits
- Eliminate Bottlenecks: Perform multiple sanding processes on a single machine.
- Versatile Finishing: Adapt quickly between sanding, cleaning, and texturing applications.
- Consistent Results: Machine-controlled sanding improves finish quality and repeatability.
- Compact Footprint: Ideal for shops with limited space but high performance needs.
- User-Friendly Operation: Simple controls and quick adjustments reduce setup time.
The Laguna SuperMax 13″ Combination Brush/Drum Sander SUPMX-91067 is a compact yet powerful finishing solution designed to maximize versatility, efficiency, and precision in modern woodworking environments.
