Ebac DD700 Desiccant Dehumidifier Applications
- Manufacturing and production facilities requiring controlled humidity
- Warehousing and storage of hygroscopic materials
- Industrial process environments and packaging lines
- Cold climate drying applications where refrigeration units struggle
- Corrosion prevention in mechanical rooms and equipment storage
- Moisture control for pharmaceutical, food, and chemical industries
Desiccant dehumidifiers like the DD700 excel in low temperature environments and applications requiring deep drying or extremely low humidity levels.
Ebac DD700 Desiccant Dehumidifier Specifications
| Model | DD700 |
|---|---|
| Available Voltages | 220V or 460V / 3 Phase / 60 Hz |
| Power Consumption | 7.5 kW |
| Typical Extraction | 231 Pints / Day |
| Process Airflow (Dry Air) | 410 CFM |
| Maximum Process Airflow | 883 CFM |
| Regeneration Airflow | 95 CFM |
| Process Air Duct Size | 8" |
| Regeneration Air Duct Size | 6" |
| Rotor Wheel Speed | 13.6 rph |
| Noise Level | 67 dB(A) |
| Minimum Operating Temperature | -4°F |
| Maximum Operating Temperature | 104°F |
| Dimensions (H × W × D) | 40" × 28" × 23" |
| Weight | 170 lbs |
Ebac DD700 Desiccant Dehumidifier Features
- High extraction capacity up to 231 PPD for demanding drying applications
- Dual EC high efficiency fans with variable speed for flexible installation and performance tuning
- Advanced silica gel desiccant rotor with 82% active material for consistent drying performance
- PTC regeneration heater ensures rapid moisture removal and stable operation
- Manual or automatic operating modes for flexible humidity control
- Remote humidity sensor facility allows external humidistat connection for automated operation
- Electronic thermostat and control panel for adjustable drying performance settings
- Multiple drying modes including High Extraction, High Efficiency, and Deep Drying
- Dual air inlet design allowing separation of regeneration and process air streams
- Integrated process and regeneration air filtration for reliable long-term operation
- High temperature safety cut-outs protecting the system under demanding operating conditions
- Rubber anti-vibration feet for quiet and stable operation
How the DD700 Desiccant Dehumidifier Works
- Air is drawn into the unit as process air.
- The air passes through a rotating silica gel desiccant rotor.
- Moisture is absorbed by the desiccant material as the air moves through the wheel.
- Dry air exits the unit and returns to the controlled space.
- A second air stream called regeneration air is heated and passed through a portion of the rotor.
- This heated air removes the moisture from the rotor.
- The moist regeneration air is exhausted from the system.
- The rotor slowly rotates to continuously regenerate and maintain drying performance.
Unlike refrigeration dehumidifiers, desiccant systems continue operating efficiently even in sub-zero environments where condensation-based systems cannot function effectively.
What’s Included
- 1 × DD700 Desiccant Dehumidifier (220V or 460V model)
- 1 × DD700 Owner’s Manual
Why Choose the Ebac DD700 Desiccant Dehumidifier
- High capacity moisture removal for industrial environments
- Efficient desiccant drying technology for cold climates
- Flexible drying modes for optimized energy usage
- Variable EC fan system for installation flexibility
- Reliable EIPL engineering with decades of industrial drying experience
The Ebac DD700 Desiccant Dehumidifier delivers powerful humidity control, reliable desiccant drying performance, and flexible installation options for industrial environments requiring consistent moisture control year-round.
