Steff Supersonic 4 Power Feeder Applications
- Shapers, table saws, and industrial router table systems
- High-precision woodworking requiring consistent feed rates
- Processing hardwoods, softwoods, composites, and delicate materials
- Applications requiring maximum stability and variable speed flexibility
Ideal for professionals who require advanced electronic speed control combined with enhanced stability from a four-roller system.
Steff Supersonic 4 Power Feeder Specifications
| Model | Supersonic 4 |
|---|---|
| Motor Power | 1 HP |
| Three-Phase Motor Power | 0.75 kW |
| Speed Control | Infinite Variable (Electronic) |
| Feed Speed Range | 0.5 – 33 m/min (Up to 82 FPM) |
| Maximum Speed (Optional Gears) | Up to 108.5 FPM |
| Number of Rollers | 4 |
| Roller Diameter | Ø120 mm (4-3/4") |
| Roller Width | 60 mm (2-1/4") |
| Roller Hardness | 50–60 Shore (Natural Rubber) |
| Vertical Travel | 1" |
| Spring Travel | 20 mm |
| Net Weight | 34 kg |
| Gross Weight | 36 kg |
| Packaging Dimensions | 670 × 570 × 330 mm |
| Country of Manufacture | Italy |
Steff Supersonic 4 Power Feeder Performance & Construction
- SMART electronic controller enables precise, real-time speed adjustments for optimal feeding performance.
- Infinite variable speed system eliminates fixed gear limitations for maximum flexibility.
- Patented VARIOPOWER technology ensures perfect grip and consistent feeding at all speeds.
- Quick forward/reverse selection enhances workflow efficiency and ease of operation.
- Four-roller feeding system provides superior stability, improved grip, and consistent material control.
- Powerful 1 HP motor delivers reliable torque for demanding woodworking applications.
- Sintered case hardened gears ensure long-lasting durability and reduced wear.
- Bronze alloy main drive gear enhances smooth operation and extends service life.
- Natural rubber rollers (60 shore) provide excellent traction while protecting workpiece surfaces.
- Optional polyurethane and steel rollers available for specialized applications.
- Calibrated spring support system maintains consistent roller pressure and feeding accuracy.
- 1" vertical travel accommodates varying material thicknesses.
- Electrostatic paint finish improves resistance to corrosion and shop wear.
- Universal support column included for flexible installation and positioning.
Steff Supersonic 4 Power Feeder Optional Accessories
- Gear Z=22 (Part #41600016)
- Gear Z=43 (Part #41600025)
Optional gears extend maximum feed speed up to 108.5 FPM for specialized high-speed applications.
Why Choose the Steff Supersonic 4 Power Feeder
- Infinite electronic speed control for unmatched precision and flexibility.
- Four-roller configuration ensures maximum stability and material control.
- Advanced VARIOPOWER system delivers consistent grip at all speeds.
- Durable Italian construction for long-term professional performance.
The Steff Supersonic 4 Power Feeder represents the ultimate combination of smart technology, precision engineering, and industrial durability—making it the ideal solution for high-performance woodworking environments.
