Safety speed SR5U Panel Saw and Router Combo Applications
- Cabinet and furniture manufacturing
- Composite panel fabrication and processing
- Woodworking and millwork shops
- Routing operations including dados, blind dados, rabbets, and grooves
- Production environments requiring both cutting and routing in one machine
Ideal for high-demand shops looking to increase production efficiency with a single, heavy-duty machine.
Safety speed SR5U Panel Saw and Router Combo Specifications
| Model | SR5U |
|---|---|
| Maximum Crosscut | 62″ / 1575 mm |
| Maximum Rip Cut | Unlimited |
| Maximum Cut Thickness | 1.75″ / 45 mm |
| Cut Accuracy | 1/64″ / 0.4 mm (straight & square) |
| Frame Length | 120″ / 3050 mm |
| Machine Dimensions | 124″ × 17″ × 92″ |
| Weight | 589 lbs (Shipping: 623 lbs / 283 kg) |
| Saw Motor | 3 HP, 13 Amp, Worm Drive |
| Router Motor | 3+ HP, 15 Amp, Variable Speed |
| Voltage | 120V |
| Saw Blade Diameter | 8″ / 210 mm |
| Router Bit Compatibility | 1/4″ or 1/2″ collet |
| Guide Tubes | Chrome-Plated 1.75″ Steel |
| Bearing System | 8 Nylatron Roller Bearings |
| Material Rollers | Solid Aluminum |
| Certifications | TUV Certified to UL/CSA Standards |
| Country of Origin | USA |
Safety speed SR5U Panel Saw and Router Combo Features & Performance
- Heavy-duty worm drive saw motor delivers enhanced torque and cutting power for demanding applications.
- 3+ HP variable speed router motor provides superior routing performance across various materials.
- Quick-change system allows switching between saw and router in under one minute.
- Patented floating router carriage ensures consistent depth control and precision routing.
- Solid aluminum material rollers improve durability and support high-production workflows.
- 10 ft. welded steel frame provides maximum rigidity and long-term structural integrity.
- Chrome-plated 1.75″ guide tubes ensure smooth and accurate carriage movement.
- 8 Nylatron bearing system supports precision cutting with minimal maintenance.
- Enclosed counterweight system enables smooth and controlled vertical operation.
- Integrated dust collection bonnets connect easily to dust extraction systems.
- Thin material pressure guard secures lightweight panels during cutting.
- MID-WAY FENCE™ with flip stop allows ergonomic, waist-level processing of smaller panels.
- 4 material clamps and blind dado stops enhance routing accuracy and repeatability.
- Supports vertical and horizontal cutting and routing for maximum versatility.
Safety speed SR5U Panel Saw and Router Combo Cutting & Routing Capabilities
- Handles full-size panels with efficient single-operator control
- Performs precise vertical and horizontal panel cutting
- Executes routing operations including plow cuts, cross dados, blind dados, and rabbets
- Maintains consistent routing depth with floating router head technology
- Unlimited rip capacity for flexible material sizing
Why Choose the Safety speed SR5U Panel Saw and Router Combo
- Upgraded power with worm drive saw and 3+ HP router motor
- Built for higher production environments and demanding workloads
- Combines cutting and routing into one efficient machine
- High precision accuracy of 1/64″ for professional results
- Durable construction with aluminum rollers for long-term use
The Safety Speed SR5U Panel Saw and Router Combo is the ultimate solution for high-production shops seeking maximum power, precision, and efficiency in a single, space-saving machine.
