Safetyspeed H5 Panel Saw with 64″ Cutting Height Applications
- Cabinet and furniture manufacturing shops
- Millwork and woodworking facilities
- Plastic, composite, and aluminum panel cutting
- Small to mid-size production environments
- Workshops requiring accurate vertical and horizontal panel processing
Ideal for shops needing a reliable, space-saving panel saw for consistent daily cutting between 1–3 hours.
Safetyspeed H5 Panel Saw with 64″ Cutting Height Specifications
| Model | H5 |
|---|---|
| Maximum Crosscut | 64″ / 1625 mm |
| Maximum Rip Cut | Unlimited |
| Maximum Cut Depth | 1.75″ / 45 mm |
| Cut Accuracy | 1/32″ / 0.8 mm (straight & square) |
| Frame Length | 120″ / 3050 mm |
| Machine Dimensions | 120″ × 11″ × 83″ |
| Weight | 298 lbs |
| Shipping Weight | 410 lbs / 186 kg |
| Motor | 3.25 HP, 15A, 120V (220V option available) |
| Motor Manufacturer | Milwaukee Tool |
| Saw Blade Diameter | 8″ / 210 mm |
| Saw Blade Bore | 5/8″ |
| Rollers | 14 Injection-Molded Rollers |
| Guide Tubes | Zinc Plated 1.75″ Steel |
| Daily Usage | 1–3 Hours |
| Country of Origin | USA |
| Certifications | TUV Certified to UL/CSA Standards |
Safetyspeed H5 Panel Saw with 64″ Cutting Height Features & Construction
- 10’ welded steel frame provides rigidity and long-term durability for precision cutting.
- Zinc-plated 1.75″ steel guide tubes ensure smooth carriage travel and corrosion resistance.
- Milwaukee Tool motor delivers dependable cutting power for consistent performance.
- 4 Nylatron roller bearing systems enhance glide accuracy and reduce friction.
- Quick change cutting orientation allows fast transitions between vertical and horizontal cuts.
- Adjustable vertical and horizontal rulers improve measurement accuracy and repeatability.
- Spring-loaded counterbalance system provides smooth and controlled saw movement.
- Thin material pressure guard secures lightweight materials during cutting operations.
- Integrated dust collection bonnet supports connection to external dust extraction systems.
- Injection-molded rollers protect material surfaces while ensuring stable positioning.
- Extended warranty adds long-term value and reliability assurance.
Safetyspeed H5 Panel Saw with 64″ Cutting Height Accessories
- Fixed stand for stable installation
- 8″ high-performance saw blade
- Dust collection kit compatible with shop vacuum systems
- Extension kits adding 22″ support on each side
Why Choose the Safetyspeed H5 Panel Saw with 64″ Cutting Height
- Full-size panel saw performance at an affordable price point
- Precision accuracy of 1/32″ for professional-quality cuts
- 64″ crosscut capacity with unlimited rip capability
- Durable steel construction built for daily shop use
- Efficient design for small to mid-sized production environments
The Safetyspeed H5 Panel Saw with 64″ Cutting Height delivers professional-grade precision, reliability, and versatility—making it an ideal solution for shops seeking high performance without the cost of larger industrial systems.
