Safetyspeed H4 Panel Saw with 50″ Maximum Cutting Height Applications
- Cutting full 4' x 8' plywood, MDF, and composite panels
- Cabinet and furniture manufacturing
- Woodworking and fabrication shops
- Panel processing for construction and millwork
- General-purpose industrial cutting applications
A preferred solution for shops requiring accurate, full-sheet processing with efficient one-person operation.
Safetyspeed H4 Panel Saw with 50″ Maximum Cutting Height Specifications
| Model | H4 |
|---|---|
| Maximum Crosscut | 50" (1270 mm) |
| Maximum Rip Cut | Unlimited |
| Maximum Cut Depth | 1 3/4" (45 mm) |
| Cut Accuracy | 1/32" (0.8 mm) |
| Frame Length | 120" (10 ft) |
| Saw Blade Diameter | 8" (210 mm) |
| Saw Blade Bore | 5/8" |
| Motor | 3.25 HP, 15 Amp, 120V (220V Available) |
| Motor Manufacturer | Milwaukee Tool |
| Rollers | 14 |
| Machine Weight | 244 lbs |
| Dimensions | 120" x 11" x 70" |
| Country of Origin | USA |
Safetyspeed H4 Panel Saw with 50″ Maximum Cutting Height Performance & Construction
- Full 10' Welded Steel Frame provides rigidity and stability for full-size panel processing.
- Precision Guide Tube System with zinc-plated steel tubes ensures smooth, accurate cutting.
- Industrial Milwaukee Motor delivers reliable power for consistent performance.
- Spring Counterbalance System allows controlled, effortless saw carriage movement.
- Quick Vertical/Horizontal Changeover improves workflow efficiency.
- Integrated Dust Collection Bonnet helps maintain a cleaner workspace.
- Thin Material Pressure Guard enhances accuracy when cutting lightweight materials.
- Heavy-Duty Guarded Saw Blade improves operator safety during cutting operations.
Safetyspeed H4 Panel Saw with 50″ Maximum Cutting Height Standard Equipment
- 3.25 HP industrial-duty saw motor
- Zinc-plated 1 ¾" steel guide tubes
- 4 Nylatron roller bearing systems
- Adjustable vertical and horizontal rulers
- Thin material pressure guard
- Injection-molded material rollers
- Spring-loaded counterbalance system
- Integrated dust collection bonnet
- Extended warranty
- TUV certified to UL/CSA standards
Why Choose the Safetyspeed H4 Panel Saw with 50″ Maximum Cutting Height
- Full-size panel processing with a 10' industrial frame.
- Accurate cuts within 1/32" across a wide range of materials.
- Unlimited rip capacity for flexible cutting applications.
- One-person operation for efficient workflow.
- Durable, low-maintenance design for long-term use.
The Safetyspeed H4 Panel Saw with 50″ Maximum Cutting Height delivers industrial-level cutting performance, precision, and reliability—making it an ideal solution for professional woodworking and panel processing environments.
