Proxxon Radius Turning Attachment for PD 230/E & PD 250/E Highlights
- Radii and spheres: It turns convex and concave shapes, radii or 3/4 spheres up to a maximum of 32 mm.
- Height-adjustable holder: The boring tool tip adjusts from 30 to 45 mm above the cross slide.
- Broad lathe compatibility: It works with the FD 150/E, PD 250/E, PD and older Proxxon lathes.
- Cutter included: A finishing cutter of 8 x 8 x 80 mm is supplied.
- Compact footprint: The base plate measures 67 x 50 mm with a height of 55 mm, and it comes in a wooden box with sliding lid.
Proxxon Radius Turning Attachment for PD 230/E & PD 250/E Compatibility & What's Included
- Fits PD 230/E, PD 250/E, FD 150/E and older Proxxon lathes
- Includes 8 x 8 x 80 mm finishing cutter
Proxxon Radius Turning Attachment for PD 230/E & PD 250/E Specifications
| Brand | Proxxon |
|---|---|
| Item No. | 24062 |
| Max. Radius/Sphere | 32 mm |
| Base Plate | 67 x 50 mm |
| Height | 55 mm |
| Country of Origin | Germany |
| Product Size | 5.2 x 3.39 x 2.44 in |
| Package Size | 9 x 9 x 4 in |
| Shipping Weight | 3 lbs. |
| EAN / UPC | 4006274240629 |
Ideal For: Machinists and model makers who need accurate rounded contours on the lathe.
