System Highlights
- Symmetrical Balanced Zoning: Three matched 12,000 BTU cassettes deliver an even 36,000 BTU total connected capacity, perfectly conditioning three independent spaces up to 500 sq. ft. each.
- OuttaSight™ Architectural Design: Flush-mount ceiling cassette profile sits discreetly between standard ceiling joists, utilizing the included low-profile trim kits (`DIY-CAS-TRIM-O`) to preserve valuable wall space and interior aesthetics.
- 1-Way Directional Airflow: Precision louver control directs high-velocity conditioned air across the room for even thermal distribution without direct drafts, operating at a sleek profile of 50.31" W x 13.19" D.
- Expandable 48K Condenser Chassis: Deploys out of the box as a robust tri-zone system, leaving immense reserve headroom to hook up three additional handlers as your property scales.
- True DIY Installation Workflow: Patented pre-charged Quick Connect® lines completely eliminate conventional line evacuation, vacuuming, and professional trade labor requirements.
Engineered for homeowners who demand architectural, low-profile ceiling cassette integration across three balanced zones, offering maximum long-term expansion flexibility from a single centralized 48K condenser framework.
Technical Specifications
| Total Connected Capacity | 36,000 BTU (12K + 12K + 12K Ceiling Cassettes) |
|---|---|
| Condenser Model | DIY-MULTI6-48HP230D-O (6-Zone Capable) |
| SEER2 / EER2 Rating | SEER2 21.8 | EER2 12.0 |
| Heating Efficiency (HSPF2) | HSPF2-4: 10.0 | HSPF2-5: 7.8 |
| Electrical Interface Requirements | 208–230V, 1 Phase, 60 Hz (45A Max Breaker / 40A MCA) |
| Refrigerant Type | R-454B (Pre-Charged Eco-Friendly) |
| Industry Compliance Certifications | UL Listed, ETL Listed, ENERGY STAR, AHRI Certified |
Zone Configuration & Performance Metrics
| Specification / Feature | Zone 1: 12K Cassette | Zone 2: 12K Cassette | Zone 3: 12K Cassette |
|---|---|---|---|
| Cooling / Heating Output | 12,000 BTU | 12,000 BTU | 12,000 BTU |
| Coverage Area | 351 to 500 sq. ft. | 351 to 500 sq. ft. | 351 to 500 sq. ft. |
| Lineset Interconnect Size | 1/4" Liquid • 1/2" Suction | 1/4" Liquid • 1/2" Suction | 1/4" Liquid • 1/2" Suction |
| Lineset Length Options | 16 ft, 25 ft, 35 ft, or 50 ft | 16 ft, 25 ft, 35 ft, or 50 ft | 16 ft, 25 ft, 35 ft, or 50 ft |
| Unit Dimensions & Weight | 50.31"W x 13.19"D x 8.98"H (45 lbs) | 50.31"W x 13.19"D x 8.98"H (45 lbs) | 50.31"W x 13.19"D x 8.98"H (45 lbs) |
Advanced Engineering & Warranty
- Gold Fin® Corrosion Protection: Advanced clear-coat protective barrier shields the exterior condenser coil against extreme humidity and harsh coastal climates.
- DC Inverter Drive Architecture: The continuous variable-speed rotary inverter compressor scales its operating frequency down precisely to match ambient thermal loads, completely avoiding costly current draw spikes.
- Smart Ecosystem Control: Full out-of-the-box integration via Amazon Alexa, Google Assistant, and the dedicated SmartHVAC mobile app for remote multi-zone scheduling and mode adjustments.
- 7-Year Compressor Warranty: Commercial-grade structural factory backing ensuring the heart of your outdoor condenser system remains protected against manufacturing defects.
- 5-Year Parts Protection Framework: Comprehensive hardware replacement coverage across internal circuit boards and critical operational components.
