Mrcool Advantage 5th Gen 36k BTU 230V Condenser A-36-HP-C-230D-O Applications
- Large residential homes, open floor plans, and expansive living areas up to 1,550 sq. ft.
- Light commercial spaces, offices, and retail environments
- Single-zone ductless mini-split HVAC systems
- Energy-efficient upgrades for large-area climate control
Engineered for maximum performance in large spaces requiring powerful, efficient, and reliable heating and cooling.
Mrcool Advantage 5th Gen 36k BTU 230V Condenser A-36-HP-C-230D-O Specifications
| Brand | MRCOOL |
|---|---|
| Series | Advantage 5th Gen |
| Model | A-36-HP-C-230D-O |
| Unit Type | Mini-Split Condenser |
| Tonnage | 3 Ton |
| Cooling Capacity | 36,000 BTU |
| Heating Capacity | 36,000 BTU |
| SEER2 | 18 |
| EER2 | 9 |
| HSPF2-4 | 8.5 |
| Voltage | 208–230V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse Breaker | 35 A |
| Min Circuit Ampacity | 33 A |
| Zone Capacity | 1 |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 112.88 oz |
| Sound Level | 60.5 dBA |
| Compressor Type | Rotary (DC Inverter) |
| Max Line Set Length | 213.2 ft |
| Liquid Line Size | 3/8" |
| Suction Line Size | 5/8" |
| Dimensions (W × H × D) | 37.24" × 31.89" × 16.14" |
| Net Weight | 150.35 lbs |
| Certifications | UL, CSA, ETL, AHRI |
Mrcool Advantage 5th Gen 36k BTU 230V Condenser A-36-HP-C-230D-O Performance & Features
- Maximum Capacity Output designed to handle large spaces with strong, consistent airflow.
- Eco-Friendly R-454B Refrigerant reduces global warming potential by approximately 80% compared to older refrigerants.
- DC Inverter Technology delivers precise temperature control and improved energy efficiency.
- Smart HVAC Compatibility enables control via mobile app, Amazon Alexa, and Google Assistant.
- Gold Fin® Coating enhances corrosion resistance for long-lasting outdoor durability.
- Quiet Operation engineered to maintain performance while minimizing operational noise.
- Advanced Safety Features including overload protection and refrigerant monitoring.
- Professional Installation Required ensures optimal performance and system longevity.
Why Choose the Mrcool Advantage 5th Gen 36k BTU 230V Condenser A-36-HP-C-230D-O
- High-capacity heating and cooling for large residential or commercial spaces
- Energy-efficient operation with environmentally friendly refrigerant
- Smart home integration for convenient climate control
- Durable outdoor construction with corrosion-resistant coating
- Backed by MRCOOL® warranty for long-term peace of mind
The Mrcool Advantage 5th Gen 36k BTU 230V Condenser A-36-HP-C-230D-O delivers powerful, efficient, and intelligent climate control, making it an ideal solution for large spaces requiring dependable, energy-conscious performance.
