Mrcool Advantage 5th Gen 24k BTU 230V Condenser A-24-HP-C-230D-O Applications
- Large living rooms, open-concept areas, and residential spaces up to 1,050 sq. ft.
- Single-zone ductless mini-split HVAC systems
- Home additions, garages, and workshops
- Energy-efficient HVAC upgrades and replacements
Ideal for large spaces requiring powerful, efficient, and environmentally conscious heating and cooling performance.
Mrcool Advantage 5th Gen 24k BTU 230V Condenser A-24-HP-C-230D-O Specifications
| Brand | MRCOOL |
|---|---|
| Series | Advantage 5th Gen |
| Model | A-24-HP-C-230D-O |
| Unit Type | Mini-Split Condenser |
| Tonnage | 2 Ton |
| Cooling Capacity | 24,000 BTU |
| Heating Capacity | 24,000 BTU |
| SEER2 | 18.7 |
| EER2 | 10 |
| HSPF2-4 | 9.3 |
| Voltage | 208–230V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse Breaker | 20 A |
| Min Circuit Ampacity | 19 A |
| Zone Capacity | 1 |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 53.62 oz |
| Sound Level | 59.5 dBA |
| Compressor Type | Rotary (DC Inverter) |
| Max Line Set Length | 164 ft |
| Liquid Line Size | 3/8" |
| Suction Line Size | 5/8" |
| Dimensions (W × H × D) | 35.04" × 26.5" × 13.46" |
| Net Weight | 94.58 lbs |
| Certifications | UL, CSA, ETL, AHRI |
Mrcool Advantage 5th Gen 24k BTU 230V Condenser A-24-HP-C-230D-O Performance & Features
- High-Capacity Performance delivers strong, consistent airflow for large spaces.
- Eco-Friendly R-454B Refrigerant reduces global warming potential by approximately 80% compared to older refrigerants.
- DC Inverter Technology ensures precise temperature control and enhanced efficiency.
- Smart HVAC Compatibility supports control via mobile app, Amazon Alexa, and Google Assistant.
- Gold Fin® Coating protects against corrosion for long-lasting outdoor durability.
- Quiet Operation designed to maintain comfort with minimal noise for its capacity class.
- Advanced Safety Features including overload protection and refrigerant monitoring.
- Professional Installation Required ensures optimal system performance and longevity.
Why Choose the Mrcool Advantage 5th Gen 24k BTU 230V Condenser A-24-HP-C-230D-O
- High-capacity heating and cooling for large residential spaces
- Energy-efficient performance with environmentally friendly refrigerant
- Smart home integration for convenient control
- Durable outdoor construction with corrosion resistance
- Backed by MRCOOL® warranty for peace of mind
The Mrcool Advantage 5th Gen 24k BTU 230V Condenser A-24-HP-C-230D-O is a powerful, efficient, and reliable outdoor unit designed to deliver consistent comfort, lower energy costs, and environmentally responsible performance for larger spaces.
