Mrcool Advantage 5th Gen 12k BTU 230V Condenser A-12-HP-C-230D-O Applications
- Bedrooms, living rooms, and residential spaces up to 500 sq. ft.
- Single-zone ductless mini-split HVAC systems
- Home additions, garages, and workshops
- Energy-efficient HVAC upgrades and replacements
Ideal for medium-sized spaces requiring efficient, quiet, and environmentally responsible climate control.
Mrcool Advantage 5th Gen 12k BTU 230V Condenser A-12-HP-C-230D-O Specifications
| Brand | MRCOOL |
|---|---|
| Series | Advantage 5th Gen |
| Model | A-12-HP-C-230D-O |
| Unit Type | Mini-Split Condenser |
| Tonnage | 1 Ton |
| Cooling Capacity | 12,000 BTU |
| Heating Capacity | 12,000 BTU |
| SEER2 | 21.3 |
| EER2 | 10.8 |
| HSPF2-4 | 9.1 |
| Voltage | 208–230V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse Breaker | 15 A |
| Min Circuit Ampacity | 13 A |
| Zone Capacity | 1 |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 24.69 oz |
| Sound Level | 54 dBA |
| Compressor Type | Rotary (DC Inverter) |
| Max Line Set Length | 82 ft |
| Liquid Line Size | 1/4" |
| Suction Line Size | 3/8" |
| Dimensions (W × H × D) | 30.12" × 21.85" × 11.93" |
| Net Weight | 59.08 lbs |
| Certifications | UL, CSA, ETL, AHRI |
Mrcool Advantage 5th Gen 12k BTU 230V Condenser A-12-HP-C-230D-O Performance & Features
- High-Efficiency Performance with up to 21.3 SEER2 for reduced energy consumption and operating costs.
- Eco-Friendly R-454B Refrigerant lowers global warming potential while improving overall efficiency.
- DC Inverter Technology ensures precise temperature control and consistent system performance.
- Smart HVAC Compatibility supports mobile app control and integration with Alexa and Google Assistant.
- Gold Fin® Coating enhances corrosion resistance for long-term outdoor durability.
- Quiet Operation engineered for low noise levels without sacrificing performance.
- Advanced Safety Features including overload protection and refrigerant monitoring.
- Professional Installation Required ensures optimal performance and system longevity.
Why Choose the Mrcool Advantage 5th Gen 12k BTU 230V Condenser A-12-HP-C-230D-O
- Efficient heating and cooling for medium-sized residential spaces
- Environmentally friendly refrigerant with reduced GWP
- Smart home integration for convenient climate control
- Durable outdoor construction with corrosion-resistant coating
- Backed by MRCOOL® warranty for long-term peace of mind
The Mrcool Advantage 5th Gen 12k BTU 230V Condenser A-12-HP-C-230D-O delivers reliable, energy-efficient performance with modern smart features, making it an excellent choice for homeowners seeking comfort, efficiency, and sustainability.
