MRCOOL 5th Gen DIY 36K BTU Condenser Applications
- High-capacity primary heating and cooling for large residential spaces between 1,000 and 1,500 sq. ft.
- Climate control for sprawling open-concept areas, massive workshops, or commercial workspaces.
- Coastal or high-humidity installations requiring the advanced corrosion resistance of Gold Fin® coating.
- System replacements or upgrades demanding the latest environmentally friendly R-454B refrigerant standards.
The perfect heavy-duty outdoor power plant for homeowners seeking commercial-grade 3-ton capacity without the exorbitant costs of professional HVAC contractor installation.
MRCOOL 5th Gen DIY 36K BTU Condenser Specifications
| SKU | DIY-36-HP-C-230D25-O |
|---|---|
| UPC | 840255586986 |
| Capacity | 36,000 BTU (3.0 Ton) |
| Efficiency Ratings | 18.0 SEER2 / 8.5 EER2 / 8.5 HSPF2-4 |
| Power Supply | 208/230V / 60 Hz / 1-Phase |
| Min Circuit Ampacity / Max Fuse | 33A / 35A |
| Refrigerant Type | R-454B (109.7 oz Volume) |
| Compressor Type | DC Inverter / Rotary |
| Noise Level (Outdoor) | 60.5 dBA |
| Lineset Sizing | 3/8" Liquid / 5/8" Suction (Max Length: 213.2 ft) |
| Net Dimensions (W×H×D) | 37.24" × 31.89" × 16.14" |
| Net Weight | 152.12 lbs |
| Certifications | NEEP ccASHP, Intertek, UL Listed, ETL Listed, AHRI Certified |
MRCOOL 5th Gen DIY 36K BTU Condenser Features & Technology
- True DIY Installation: Integrates perfectly with MRCOOL pre-charged Quick Connect® line sets, allowing for safe setup without a vacuum pump.
- Gold Fin® Condenser: Built to withstand the harshest elements, the anti-corrosive coating significantly extends the operational lifespan of the unit, especially near the coast.
- Auto-Restart Function: Automatically retains previous operating settings and seamlessly resumes operation following a power outage.
- Advanced DC Inverter: The variable-speed rotary compressor dynamically adjusts power output to maximize energy efficiency while maintaining exact temperature control.
- DIYPRO® Cable Compatible: Designed to work with the 5th Gen DIYPRO® communication cable, eliminating the need for traditional electrical conduit.
Downloads & Documentation
Why Choose the MRCOOL 5th Gen DIY 36K Condenser
- Delivers an incredible 3.0 Tons of heating and cooling power with an energy-saving 18 SEER2 rating.
- Empowers you to completely bypass expensive professional HVAC labor and specialized tools.
- Ensures long-term reliability in harsh climates with heavy-duty Gold Fin® construction.
- Protected by an industry-leading 7-year compressor and 5-year parts warranty.
Combining cutting-edge inverter technology, massive output, and straightforward DIY installation, the MRCOOL® 36k 5th Gen Mini-Split Condenser offers a robust, worry-free solution for large-scale residential comfort.
