LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe Applications
- Oil & gas pipe machining and large bore tubular work
- Heavy equipment, mining, and energy sector manufacturing
- Shipbuilding and large structural component turning
- Repair and overhaul of oversized shafts and rollers
- Precision threading, boring, and taper turning of large components
Ideal for operations demanding extreme bore size, extended bed capacity, and heavy-duty cutting performance.
LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe Specifications
| Model | SHA-36 |
|---|---|
| Swing Over Bed | 36″ |
| Swing Over Cross Slide | 25″ |
| Swing in Gap | 55″ |
| Width of Gap | 20″ |
| Distance Between Centers | 59″ – 393″ |
| Spindle Bore Options | 4⅛″, 6″, 9″, or 10″ |
| Spindle Nose | A2-11, A2-15, or A2-20 |
| Spindle Speed Range | 3–300 / 4–400 RPM (4⅛″, 6″) • 3–320 / 5–500 RPM (9″, 10″) |
| Number of Speeds | 12 Changes |
| Longitudinal Feeds | 0.0034″ – 0.40″ / rev |
| Cross Feeds | 0.0017″ – 0.20″ / rev |
| Inch Threads | 1/4 – 30 TPI |
| Metric Threads | 1 – 120 mm |
| Diametral Pitch Threads | 1 – 120 DP |
| Module Pitch Threads | 0.25 – 30 MP |
| Leadscrew | 2 1/4″ Diameter, 2 TPI |
| Cross Slide Travel | 24″ |
| Compound Rest Travel | 14″ |
| Rapid Traverse Speed | 80″ / min |
| Tailstock Quill Diameter | 4⅛″ |
| Tailstock Quill Travel | 11 1/4″ |
| Bed Width | 22″ |
| Main Motor | 15 HP, 20 HP, or 25 HP |
| Rapid Traverse Motor | 1 HP |
| Approximate Weight | 14,991 – 33,730 lbs (varies by length) |
LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe Performance & Construction
- FC-25 high-strength cast iron bed with box-type lower structure ensures rigidity and effective chip management.
- One-piece forged spindle supported by precision bearings for superior stability and accuracy.
- Ni-Cr-Mo alloy gears and shafts that are carburized and precision ground for durability and long service life.
- 12-step spindle speed system designed for optimized torque and cutting performance.
- Electromagnetic brake system provides precise control and rapid stopping capability.
- Fully enclosed gearbox supports inch, metric, module, and diametral threading without gear changes.
- Forced lubrication system ensures consistent performance and reduces wear on critical components.
- Safety clutch and overload protection maintain safe and reliable operation.
- Advanced carriage and apron system with automatic lubrication and interlock safety features.
- Rapid traverse system for efficient longitudinal and cross feed movement.
- Taper attachment capability allowing precision taper turning up to ±10°.
LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe Standard Equipment
- Coolant system with pump
- Full-length splash guard
- Longitudinal rapid traverse
- Safety red spindle brake pedal
- LED work light
- Leveling pads
- Spindle center sleeve
- Two-speed tailstock
- Dead centers
- Steady rest with roller jaws (70–430mm capacity)
- 4-way quick turn turret tool post
- Thread indicator
- Operation manual and parts list
- Toolbox with tools and touch-up paint
LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe Optional Accessories
- Newall digital readout system (installed)
- Quick change tool post with holders
- Precision live center
- Keyless drill chuck and arbor
- Additional steady rest
- Follow rest
- Taper attachment
- 3-jaw scroll chuck
- 4-jaw independent chuck
Why Choose the LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe
- Extreme large bore capacity up to 10 inches for pipe and tubular work
- Extended turning length up to 393 inches for oversized components
- Heavy-duty cast construction for maximum rigidity and stability
- Advanced gearbox and threading versatility without gear changes
- Industrial-grade safety, lubrication, and braking systems
The LeBlond RKL-3600G (SHA) Series Large Bore Heavy Duty Precision Lathe is a top-tier solution for manufacturers requiring maximum capacity, precision, and durability in large-scale machining operations.
