LeBlond RKL2000G Manual Geared Head Lathe Applications
- Heavy-duty turning, facing, threading, and boring operations
- Machining large shafts, rollers, and oversized industrial components
- Production machine shops, maintenance facilities, and toolrooms
- Working with steel, alloy materials, and high-strength metals
Ideal for operations requiring maximum swing capacity, high torque, and stable machining of long and heavy workpieces.
LeBlond RKL2000G Manual Geared Head Lathe Specifications
| Model | RKL-2000G |
|---|---|
| Swing Over Bed | 21.34″ |
| Distance Between Centers | 40″ / 60″ / 83.46″ |
| Swing Over Cross Slide | 15.23″ |
| Swing in Gap | 28.74″ |
| Cross Slide Travel | 11.81″ |
| Top Slide Travel | 5.9″ |
| Bed Width | 12.5″ |
| Spindle Nose | D1-8 |
| Spindle Bore | 3.149″ |
| Spindle Taper Adapter | MT 5 |
| Spindle Speeds | 12 Speed Selections |
| Spindle Speed Range | 26 – 1500 RPM |
| Main Motor | 12.5 HP |
| Voltage | 480V / 3PH / 60Hz (other voltages available) |
| Coolant Motor | 1/8 HP |
LeBlond RKL2000G Manual Geared Head Lathe Threading & Feed Capacity
| Inch Threads | (45) 2 to 72 TPI |
|---|---|
| Metric Threads | (39) 0.2 to 14 mm |
| Modular Threads | (18) 0.3 to 3.5 |
| Diametral Threads | (21) 8 to 44 |
| Lead Screw Diameter | 1.25″ |
| Lead Screw Pitch | 4 TPI |
| Longitudinal Feed | 0.0015 to 0.04 IPR |
| Cross Feed | 0.00075 to 0.02 IPR |
LeBlond RKL2000G Manual Geared Head Lathe Headstock & Spindle
- Forged alloy steel spindle is hardened, ground, and dynamically balanced for precision performance.
- D1-8 cam-lock spindle mount supports heavy-duty workholding applications.
- 3.149″ spindle bore accommodates larger stock diameters.
- 12-speed geared headstock delivers consistent torque up to 1500 RPM.
- Precision bearing system ensures long-lasting accuracy and smooth operation.
- Constant oil bath lubrication protects gears and bearings during extended use.
LeBlond RKL2000G Manual Geared Head Lathe Bed & Construction
- One-piece cast iron base provides superior rigidity and vibration control.
- Meehanite cast wide bed is stress relieved for dimensional stability.
- Induction hardened bed ways (HRC 48–55) ensure long-term durability.
- Precision ground and hand-scraped bed enhances accuracy and smooth carriage travel.
- Removable gap bed allows machining of larger diameter parts.
- Large removable chip tray simplifies maintenance and chip removal.
LeBlond RKL2000G Manual Geared Head Lathe Tailstock Specifications
| Quill Diameter | 2.322″ |
|---|---|
| Quill Travel | 5.0″ |
| Quill Inside Taper | MT 4 |
LeBlond RKL2000G Manual Geared Head Lathe Standard Equipment
- Coolant system with electric pump
- Chuck guard with operator safety interlock
- Removable front chip pan
- Adjustable apron infeed overload safety clutch
- Lockable main disconnect switch
- LED work light
- Leveling pads
- Operation manual and parts list
- Tool box and tools
- Steady rest with roller jaws (1.6″–8.7″ capacity)
- Follow rest with roller jaws (0.6″–3.3″ capacity)
- Telescopic taper attachment
- 4-way quick turn tool post
- 14″ face plate
- Safety red spindle brake pedal
- Full-length splash guard
- Dead centers (2)
- Spindle center sleeve (MT5)
Why Choose the LeBlond RKL2000G Manual Geared Head Lathe
- 21″ swing capacity for handling larger workpieces
- Extended between centers up to 90″ for long parts
- Powerful 12.5 HP motor for heavy-duty machining
- 12-speed geared headstock for versatile operation
- Rigid construction ensures consistent accuracy and reliability
The LeBlond RKL2000G Manual Geared Head Lathe is a powerful and reliable solution for machinists who need increased capacity, durability, and precision in large-scale turning applications.
