Laguna U|30 Metal Dust Collector MDC503L2203 Applications
- Large metal fabrication and production shops
- Multi-machine dust collection systems
- Grinding, sanding, deburring, and finishing stations
- Industrial environments requiring high airflow and efficient dust control
Best suited for operations requiring higher airflow capacity and simultaneous connection to multiple machines.
Laguna U|30 Metal Dust Collector MDC503L2203 Specifications
| Model | MDC503L2203 |
|---|---|
| Motor | 3 HP |
| Motor Speed | 3450 RPM |
| Electrical | 220V / 60 Hz / 1 Phase |
| Amperage | 11 FLA |
| Switch | Magnetic |
| Power Cord | 6 ft |
| Plug | No Plug |
| Inlet Size | Four 4" Inlets |
| Maximum Airflow | 957 CFM |
| Static Pressure | 9.4" H2O |
| Noise Level | 74 dB |
| Impeller Size | 12" Diameter |
| Collection Volume | 5.6 Gallons |
| Filter Material | Galvanized Micro Mesh (Fire-Resistant) |
| Filter Size | 19.25" x 25" x 1.8" |
| Construction | Steel Cart with Stainless Drum |
| Start Capacitor | 600 µF / 125V |
| Run Capacitor | 450 µF / 350V |
| Wheels | 2.5" Machine / 2" Drum Casters |
| Assembled Size (L x W x H) | 35.4" x 24.6" x 40" |
| Shipping Size (L x W x H) | 35" x 26" x 42" |
| Weight (Net / Gross) | 230.5 lb / 253.5 lb |
Laguna U|30 Metal Dust Collector MDC503L2203 Performance & Construction
- Powerful 3 HP motor generates up to 957 CFM for high-demand dust collection applications.
- Four 4-inch inlet ports allow simultaneous connection to multiple machines for increased productivity.
- Heavy-duty steel cabinet and stainless drum ensure durability and long service life in industrial environments.
- High-efficiency micro mesh filter captures fine metal dust while maintaining airflow performance.
- Fire-resistant filtration system enhances operational safety in metalworking applications.
- Quiet operation (74 dB) reduces workplace noise despite high airflow capacity.
- Large 5.6-gallon collection drawer supports extended operation with less frequent emptying.
- Mobile design with integrated casters allows easy repositioning within the shop.
Why Choose the Laguna U|30 Metal Dust Collector MDC503L2203
- High airflow capacity ideal for larger shops and multi-machine setups.
- Industrial-grade construction for durability and long-term reliability.
- Multiple inlet ports maximize flexibility and efficiency.
- Fire-resistant filtration improves safety in metal dust environments.
- Quiet operation combined with powerful performance.
The Laguna U|30 Metal Dust Collector MDC503L2203 is a powerful, high-capacity solution designed for serious metalworking operations that require efficient, safe, and reliable dust collection across multiple machines.
