Laguna Tools P12|8 1PH Panel Saw Applications
- High-volume panel processing and sheet good sizing
- Precision miter cutting for large-format woodworking projects
- Industrial furniture manufacturing and cabinetry
- Cutting laminates, veneers, and solid wood with scoring blade precision
- Professional workshops requiring a 220V single-phase power configuration
Designed for the serious professional who needs industrial capacity and "smooth-as-silk" slider operation without the requirement for three-phase power.
Laguna Tools P12|8 1PH Panel Saw Specifications
| Motor | 5 HP / 1 Phase / 220V / 60 Hz |
|---|---|
| Main Blade Capacity | 12", 14", or 16" (300mm - 400mm) |
| Scoring Blade Size | 4-3/4" (120mm) |
| Sliding Table Dimensions | 102.36" L x 14.88" W |
| Max Cutting Height (90°) | 5-1/8" (with 16" blade) |
| Main Blade Speed | 4000 RPM |
| Rip Fence Capacity | 51" with Micro-Adjustment |
| Arbor Size | 30mm (Main) / 20mm (Scoring) |
| Dust Collection | 4-3/4" (Saw) / 4" (Guard) |
| Weight (Net/Ship) | 1815 lbs / 2112 lbs |
Laguna Tools P12|8 1PH Panel Saw Performance & Construction
- Superior Dumbbell Slider: Constructed of anodized aluminum for ultra-smooth movement and long-term durability.
- European Style Rip Fence: Features a heavy-duty casting riding on a micro-polished solid steel bar with micro-adjustment for fine-tuning.
- Versatile Guard System: Standard overhead guard with quick-change 90° and 45° guards and a swing-away function for unobstructed access.
- Precision Scoring Adjustment: Easy-to-use T-Handle adjustment through the cast top ensures perfect alignment and chip-free cuts.
- Heavy-Duty Internal Components: Solid gears, precision-machined trunnions, and heavy castings mounted to a rigid steel frame.
- Soft Start Technology: Equipped with a soft-start motor to minimize initial amperage draw and extend motor life.
Laguna Tools P12|8 1PH Panel Saw Included Accessories
- Heavy-duty anodized aluminum crosscut fence with two solid flip-stops
- Hold-down clamp for material stability during complex cuts
- 32" x 12" Steel extension table for additional material support
- Rip shoe and push handle for enhanced safety and control
- Telescoping fence function (Max extended 140")
Why Choose the Laguna Tools P12|8 1PH Panel Saw
- Industrial capacity capable of clearing 8-foot sheets effortlessly.
- Precision-machined dumbbell sliding table recognized as the industry standard for smoothness.
- Single-phase 5 HP motor provides massive power for residential or small-shop environments.
- Advanced safety features including a swing-away overhead guard and soft-start electronics.
The Laguna Tools P12|8 1PH Panel Saw offers a powerful combination of massive cutting capacity, refined European engineering, and the smooth operation required for high-precision architectural woodworking.
