Kurt Self-Centering Vise: SCD640, 8.0000" Max Jaw Opening 09212820 Applications
- CNC machining centers requiring precise workpiece centering.
- Production manufacturing environments focused on repeatability.
- Precision milling and machining operations.
- Fixture and tooling applications requiring accurate positioning.
- Multi-operation machining processes where consistent centering is critical.
- Toolrooms and prototype manufacturing facilities.
- High-precision metalworking and fabrication operations.
- Machining applications requiring secure and repeatable workholding.
The self-centering design automatically positions the workpiece along the vise centerline, helping reduce setup time, improve repeatability, and increase machining accuracy throughout production runs.
Kurt Self-Centering Vise: SCD640, 8.0000" Max Jaw Opening 09212820 Specifications
| Series | SCD640 |
|---|---|
| Jaw Width | 6.00" |
| Maximum Jaw Opening | 8.0000" |
| Minimum Jaw Opening | 1" |
| Throat Depth | 1.7350" |
| Operation Type | Manual |
| Material | Ductile Iron |
| Overall Length | 23.5000" |
| Overall Height | 4.8600" |
| Load Capacity | 5,764 lb |
| Maximum Operating Pressure | 80,000 PSI |
| Precision Rated | Yes |
| UNSPSC Code | 23271713 |
Kurt Self-Centering Vise: SCD640, 8.0000" Max Jaw Opening 09212820 Performance & Construction
- Self-Centering Vise Design automatically centers workpieces for improved machining accuracy and setup efficiency.
- Ductile Iron Construction provides exceptional strength, rigidity, and long-term durability.
- Hardened Bed Way enhances wear resistance and maintains precision throughout extended service life.
- Hardened Jaw Components improve durability and clamping reliability under demanding machining conditions.
- Accurate Matching System promotes consistent positioning and repeatable results.
- Lip Seal Protection helps prevent contamination from chips, coolant, and machining debris.
- Integrated Chip Guard protects internal components and supports smoother operation.
- Unique Adjustment Feature allows fine-tuning for optimized workholding performance.
- 80,000 PSI Operating Capability supports demanding machining applications requiring substantial holding power.
- 5,764 lb Load Capacity provides secure retention of a wide range of workpiece sizes and materials.
Why Choose Kurt Self-Centering Vise: SCD640, 8.0000" Max Jaw Opening 09212820
- Automatically centers workpieces for greater machining consistency.
- Reduces setup time and improves production efficiency.
- Precision-rated construction supports repeatable manufacturing processes.
- Hardened wear components provide long service life.
- Durable ductile iron body resists deflection and vibration.
- Large 8-inch jaw opening accommodates a wide variety of workpieces.
- Ideal for CNC machining, fixture applications, and precision manufacturing.
The Kurt Self-Centering Vise: SCD640, 8.0000" Max Jaw Opening 09212820 combines self-centering accuracy, rugged industrial construction, and precision-engineered performance to deliver dependable workholding for demanding machining environments. Designed to improve repeatability and reduce setup time, it is an excellent choice for manufacturers focused on productivity and precision.
