Kurt Machine Vise: Single-Station, 6.00" Jaw Width, 14" Jaw Opening, Stationary Base, Precision 72665839 Applications
- CNC milling and machining center operations requiring precision workholding.
- Production machining environments processing large or complex workpieces.
- Heavy-duty metalworking, fabrication, and manufacturing facilities.
- Machining straight surfaces with high accuracy and repeatability.
- Horizontal machining applications requiring secure workpiece positioning.
- Toolrooms, aerospace manufacturing, automotive production, and industrial machine shops.
Horizontal vises provide secure and accurate positioning of the workpiece during machining operations, helping improve machining precision, productivity, and consistency.
Kurt Machine Vise: Single-Station, 6.00" Jaw Width, 14" Jaw Opening, Stationary Base, Precision 72665839 Specifications
| Product Type | Machine Vise |
|---|---|
| Model Number | 640XLHS |
| Part Number | 72665839 |
| Number of Stations | 1 |
| Operation Type | Hydraulic |
| Orientation Type | Horizontal |
| Base Motion Type | Stationary |
| Jaw Width | 6.00 in. |
| Jaw Height | 1.7350 in. |
| Maximum Jaw Opening Capacity | 14 in. |
| Throat Depth | 1-31/64 in. |
| Base Length | 20.5000 in. (20-1/2 in.) |
| Base Height | 3.2500 in. (3-1/4 in.) |
| Overall Length | 24.5100 in. |
| Overall Width | 5.00 in. |
| Overall Height | 4.8600 in. |
| Vise Material | Ductile Iron |
| Maximum Clamping Force | 80,000 PSI |
| Load Capacity | 1,260 lb |
| Precision | Yes |
| For Use With | Machine Applications |
| UNSPSC Code | 27112100 |
Kurt Machine Vise: Single-Station, 6.00" Jaw Width, 14" Jaw Opening, Stationary Base, Precision 72665839 Performance & Construction
- Hydraulic Clamping System: Delivers powerful and consistent workholding pressure for demanding machining operations.
- Large 14-Inch Jaw Opening: Accommodates oversized workpieces while maintaining secure clamping performance.
- Precision Ground Components: Manufactured to support accurate part positioning and repeatable machining results.
- Heavy-Duty Ductile Iron Construction: Provides exceptional rigidity, vibration resistance, and long service life in industrial environments.
- Stationary Base Design: Maximizes stability during machining operations and helps maintain setup accuracy.
- Horizontal Workholding Configuration: Ideal for machining straight surfaces and precision milling applications.
- Flexible Mounting Options: Can be fastened to machine tables either parallel or at right angles depending on machining requirements.
- High Clamping Force: Up to 80,000 PSI clamping capability ensures secure workpiece retention under heavy cutting loads.
- Single-Station Layout: Simplifies setup and provides unobstructed access to the workpiece during machining.
- Extended Base Length: 20.5000-inch base supports larger workpieces while enhancing overall stability.
Why Choose the Kurt Machine Vise: Single-Station, 6.00" Jaw Width, 14" Jaw Opening, Stationary Base, Precision 72665839
- Hydraulic operation provides powerful and repeatable clamping performance.
- 14-inch jaw opening accommodates a wide range of workpiece sizes.
- Stationary base enhances rigidity and machining accuracy.
- Heavy-duty ductile iron construction withstands demanding production environments.
- 80,000 PSI clamping force supports aggressive machining operations.
- Precision design promotes repeatable results and reduced setup variation.
- Horizontal configuration is ideal for machining straight surfaces.
- Designed for professional machine shop, manufacturing, and CNC applications.
The Kurt Machine Vise: Single-Station, 6.00" Jaw Width, 14" Jaw Opening, Stationary Base, Precision 72665839 combines hydraulic clamping power, large-capacity workholding, and precision-engineered construction to deliver dependable performance for demanding machining operations where accuracy, rigidity, and productivity are essential.
