Kurt 5/8" Aluminum Bronze Hex, 5/16-18 Stud Thread, Symmetrical Hex Clamp 09509811 Applications
- Precision machining and CNC manufacturing operations.
- Fixture plates and modular workholding systems.
- Production manufacturing requiring repeatable positioning.
- Holding symmetrical or matching workpiece components.
- Toolroom and maintenance machining environments.
- Custom fixture building and workholding assemblies.
- Metalworking and fabrication operations.
- High-density fixture setups where compact clamps are required.
Symmetrical hex clamps are commonly used with parts that have similar matching components. Their balanced design allows consistent clamping pressure while maintaining accurate positioning throughout machining and assembly operations.
Kurt 5/8" Aluminum Bronze Hex, 5/16-18 Stud Thread, Symmetrical Hex Clamp 09509811 Specifications
| Clamp Type | Symmetrical Hex Clamp |
|---|---|
| Hex Size | 5/8" |
| Hex Height | 0.2500" (1/4") |
| Hex Head Material | Aluminum Bronze |
| Stud Thread Size | 5/16-18 |
| Thread Length | 0.7500" |
| Stud Material | Mild Steel / Alloy Steel Stud |
| Holding Force | 1,400 lb |
| Recommended Torque | 18 ft-lb |
| Number of Clamps | 6 |
| UNSPSC Code | 27112800 |
Kurt 5/8" Aluminum Bronze Hex, 5/16-18 Stud Thread, Symmetrical Hex Clamp 09509811 Features & Benefits
- Symmetrical Hex Clamp Design provides balanced clamping pressure for accurate and repeatable workholding.
- 1,400 lb Holding Force delivers dependable retention for machining and fixture applications.
- Aluminum Bronze Hex Head offers excellent wear resistance, durability, and corrosion resistance.
- 5/16-18 Threaded Stud ensures secure installation and compatibility with common fixture systems.
- 0.7500" Thread Length provides reliable engagement and stable clamp positioning.
- 18 ft-lb Torque Rating allows efficient clamping while maintaining consistent holding performance.
- Low-Profile 1/4" Hex Height helps maximize workspace around the fixture and workpiece.
- Compact 5/8" Hex Size supports high-density fixture layouts and efficient use of fixture plate space.
- Six-Clamp Package provides a complete solution for multi-point workholding setups.
- Designed for Precision Manufacturing where repeatability, consistency, and secure workpiece retention are critical.
Why Choose the Kurt 5/8" Aluminum Bronze Hex, 5/16-18 Stud Thread, Symmetrical Hex Clamp 09509811
- Provides strong 1,400 lb holding force in a compact design.
- Ideal for clamping matching or symmetrical components.
- Durable aluminum bronze construction resists wear and corrosion.
- Low-profile design maximizes fixture accessibility.
- Supports repeatable positioning for precision machining operations.
- Compatible with a wide variety of fixture and workholding systems.
- Includes six clamps for complete fixture setup flexibility.
The Kurt 5/8" Aluminum Bronze Hex, 5/16-18 Stud Thread, Symmetrical Hex Clamp 09509811 delivers precision workholding performance in a compact, durable package. With strong holding power, corrosion-resistant materials, and a symmetrical clamping design, it is an excellent choice for machining professionals seeking accuracy, repeatability, and fixture versatility.
