Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829 Applications
- Precision CNC machining and milling operations.
- Fixture and tooling plate workholding systems.
- Production manufacturing and repetitive machining environments.
- Workholding applications involving symmetrical or matching part geometries.
- Inspection, assembly, and fabrication fixtures.
- Custom workholding and modular fixturing systems.
Symmetrical hex clamps are specifically designed for use with parts that feature similar matching components, providing balanced and consistent clamping performance.
Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829 Specifications
| Product Type | Symmetrical Hex Clamp Kit |
|---|---|
| Part Number | 09509829 |
| Hex Type | Symmetrical |
| Hex Size | 15/16" |
| Hex Height | 5/16" (0.3120") |
| Holding Force | 2,200 lb |
| Torque Rating | 30 ft-lb |
| Stud Thread Size | 3/8-16 |
| Thread Length | 1" |
| Hex Head Material | Aluminum Bronze |
| Stud Material | Alloy Steel |
| Number of Clamps | 6 |
| UNSPSC Code | 27112800 |
Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829 Features & Benefits
- Symmetrical hex clamp design provides balanced clamping pressure for matching workpiece configurations.
- 2,200 lb holding force delivers secure workpiece retention during machining operations.
- Aluminum bronze clamp bodies offer durability, corrosion resistance, and dependable performance.
- Alloy steel studs provide high strength and reliable clamping force transmission.
- 3/8-16 threaded studs allow integration with a wide range of fixturing and tooling systems.
- Compact 5/16" profile height minimizes interference while maximizing machining access.
- 30 ft-lb torque capacity supports consistent and repeatable clamping performance.
- Complete six-clamp kit provides multiple clamping points for versatile setup options.
Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829 Performance & Construction
- Provides reliable clamping for precision machining and production applications.
- Supports repeatable part positioning and setup consistency.
- Low-profile design improves cutter access and machining flexibility.
- High-strength stud construction withstands demanding industrial environments.
- Designed for efficient fixture loading and quick setup changes.
- Helps reduce workpiece movement under cutting loads.
Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829 Package Contents
- 6 Symmetrical Aluminum Bronze Hex Clamps
- 6 Alloy Steel 3/8-16 Threaded Studs
- Associated Mounting Hardware and Components
Complete clamping kit designed to simplify fixture setup while providing secure and repeatable workholding performance.
Why Choose the Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829
- Designed specifically for symmetrical and matching component applications.
- 2,200 lb holding force ensures dependable workpiece retention.
- Durable aluminum bronze and alloy steel construction.
- Compact low-profile design maximizes machining accessibility.
- Includes six clamps for versatile fixture configurations.
- Ideal for precision machining, fixturing, and production manufacturing.
The Kurt 15/16" Aluminum Bronze Hex, 3/8-16 Stud Thread, Symmetrical Hex Clamp 09509829 provides a durable, low-profile, and high-strength workholding solution that delivers reliable clamping performance for symmetrical part machining and fixture applications.
