Kurt 11/16" Aluminum Bronze Hex, 1/4-20 Stud Thread, Symmetrical Hex Clamp 09509803 Applications
- CNC machining and milling operations.
- Fixture plate and modular workholding systems.
- Production manufacturing environments.
- Precision part positioning and clamping applications.
- Toolroom and prototype machining setups.
- Workholding systems requiring low-profile clamps.
- Multi-part fixture arrangements with matching component geometries.
- General metalworking and fabrication operations.
Symmetrical hex clamps are commonly used with parts that have similar matching components. Their balanced design allows secure and repeatable clamping while maintaining accessibility to the workpiece during machining operations.
Kurt 11/16" Aluminum Bronze Hex, 1/4-20 Stud Thread, Symmetrical Hex Clamp 09509803 Specifications
| Hex Type | Symmetrical |
|---|---|
| Hex Size | 11/16" |
| Hex Height | 0.1880" (3/16") |
| Stud Thread Size | 1/4-20 |
| Thread Length | 0.6250" |
| Hex Head Material | Aluminum Bronze |
| Stud Material | Alloy Steel |
| Holding Force | 987 lb |
| Torque Rating | 11 ft-lb |
| Number of Clamps | 6 |
| UNSPSC Code | 27112800 |
Kurt 11/16" Aluminum Bronze Hex, 1/4-20 Stud Thread, Symmetrical Hex Clamp 09509803 Performance & Construction
- Symmetrical Hex Design provides balanced clamping force for workpieces with matching geometries and fixture layouts.
- Aluminum Bronze Construction offers excellent durability, corrosion resistance, and long-term performance in industrial environments.
- Alloy Steel Stud Hardware delivers dependable fastening strength and durability under repeated use.
- 987 lb Holding Force provides secure workpiece retention during machining and manufacturing operations.
- 11 ft-lb Torque Rating supports consistent clamping performance while protecting fixture components.
- Low-Profile 3/16" Height minimizes interference with machining operations and maximizes tool accessibility.
- 0.625" Thread Length provides reliable engagement for fixture plate and workholding system installations.
- Compact 11/16" Hex Size enables installation in space-constrained workholding applications.
- Repeatable Positioning helps improve setup consistency and production efficiency.
- Six-Clamp Set provides a complete solution for multi-point workholding configurations.
Why Choose the Kurt 11/16" Aluminum Bronze Hex, 1/4-20 Stud Thread, Symmetrical Hex Clamp 09509803
- Provides strong and reliable 987 lb holding force.
- Low-profile design improves machining accessibility.
- Ideal for fixture plates and modular workholding systems.
- Durable aluminum bronze construction resists wear and corrosion.
- Alloy steel stud hardware ensures dependable fastening performance.
- Symmetrical design supports repeatable clamping of matching components.
- Includes six clamps for versatile workholding configurations.
The Kurt 11/16" Aluminum Bronze Hex, 1/4-20 Stud Thread, Symmetrical Hex Clamp 09509803 delivers compact, high-performance workholding for precision machining and fixture applications. With durable materials, dependable holding force, and a low-profile symmetrical design, it is an excellent choice for manufacturers seeking efficient and repeatable clamping solutions.
