JET IBG-8 Applications
- Aggressive stock removal, weld beveling, and heavy metal conditioning
- High-volume tool sharpening for industrial blades, drill bits, and lathe tooling
- Cleaning, snagging, and deburring rough structural castings and fabricated parts
- Continuous-duty edge smoothing and surface blending in commercial fabrication environments
Ideal for production floors and heavy machinery shops requiring a high-capacity, certified grinding station that maintains precision under constant load.
JET IBG-8 Specifications
| Stock Number | JT9-578008 |
|---|---|
| Model Number | IBG-8 |
| Motor Power | 1 HP, 115V, Single-Phase (1Ph) |
| Amperage / Frequency | 7A / 60 Hz |
| Maximum Speed | 3,450 RPM |
| Wheel Size (Diameter x Width) | 8" x 1" |
| Shaft / Arbor Hole Diameter | 5/8" (0.63") |
| Dust Port Size | 2-1/2" |
| Included Grinding Wheels | Vitrified 36-Grit (Coarse) & 60-Grit (Fine) Wheels |
| Overall Dimensions (L x W x H) | 21" x 13-3/4" x 14" |
| Net Weight / Gross Weight | 55.0 lbs / 60.0 lbs |
| Compliance Standards | CSA/CUS Certified • OSHA Compliant |
JET IBG-8 Performance & Construction
- Heavy-duty 1 HP capacitor motor supplies massive torque and maintains stable, consistent spindle speeds under heavy grinding pressure.
- Sealed, permanently lubricated bearings shield critical internal components from highly abrasive metallic dust for maintenance-free grinding.
- Integrated 2-1/2" dust ports provide efficient extraction to clear the workspace and manage fine particulate.
- Rigid cast iron tool rests offer dependable workpiece support for exact positioning and clean angles.
- Adjustable safety eye shields and spark guards keep operators highly protected while allowing clear line-of-sight tracking.
- Industrial toggle switch with safety key prevents unauthorized machine access or accidental startups.
- Pre-drilled heavy cast base ensures secure, vibration-free mounting to any shop stand or workbench setup.
Why Choose the JET IBG-8 Bench Grinder
- Industrial-grade capacitor motor avoids the lag common in lower-tier shop grinders.
- Full safety compliance with OSHA and CSA/CUS certifications ensures factory-floor readiness.
- Heavy-gauge casting dampens operational harmonics for flawless edge accuracy.
- Complete turnkey solution with premium fine and coarse vitrified wheels included.
The JET IBG-8 sets a new benchmark for rigid durability, technical precision, and shop floor operator safety.
