JET IBG-12 Applications
- Extreme stock removal, heavy weld beveling, and structural steel conditioning
- High-volume tool sharpening for oversized industrial blades, heavy lathe tooling, and thick chisels
- Snagging, cleaning, and deburring massive rough castings and fabricated components
- Continuous-duty metalworking in heavy machinery shops, foundries, and industrial maintenance hubs
Ideal for commercial production floors requiring maximum grinding capacity, unstoppable 230V torque, and rock-solid stability under the heaviest loads.
JET IBG-12 Specifications
| Stock Number | JT9-578012 |
|---|---|
| Model Number | IBG-12 |
| Motor Power | 2 HP, 230V, Single-Phase (1Ph) |
| Amperage / Frequency | 10A / 60 Hz |
| Maximum Speed | 1,720 RPM |
| Wheel Size (Diameter x Width) | 12" x 2" |
| Shaft / Arbor Hole Diameter | 1-1/4" |
| Dust Port Size | 2-1/2" |
| Included Grinding Wheels | Vitrified 36-Grit (Coarse) & 60-Grit (Fine) Wheels |
| Overall Dimensions (L x W x H) | 27" x 18" x 18" |
| Net Weight / Gross Weight | 238.0 lbs / 272.0 lbs |
| Compliance Standards | CSA/CUS Certified • OSHA Compliant |
JET IBG-12 Performance & Construction
- Massive 2 HP heavy-duty capacitor motor provides unstoppable torque, preventing the 12-inch wheels from bogging down under immense pressure.
- Optimized 1,720 RPM speed runs significantly cooler than high-speed grinders, ensuring aggressive stock removal without destroying the temper of your tool steel.
- Sealed, permanently lubricated bearings lock out heavy abrasive dust, ensuring years of smooth, maintenance-free grinding.
- Integrated 2-1/2" dust ports connect seamlessly to commercial extraction systems for a cleaner, safer workspace.
- Rugged cast iron tool rests supply dependable, flex-free support for manipulating heavy workpieces and setting exact angles.
- Adjustable safety eye shields and spark guards keep operators highly protected without obstructing the line of sight.
- Pre-drilled heavy cast base ensures secure, vibration-free mounting to any heavy-duty shop stand or reinforced workbench.
Why Choose the JET IBG-12 Industrial Grinder
- Unmatched 238-pound structural rigidity absorbs all harmonic vibration for glass-smooth tracking.
- Industrial-grade 230V architecture delivers the sustained power required for heavy metal fabrication.
- Oversized 12-inch wheel capacity extends abrasive life and provides a massive contact surface.
- Full OSHA and CSA compliance ensures the machine is ready for immediate deployment on stringent factory floors.
The JET IBG-12 is the definitive grinding solution for facilities that demand the absolute highest levels of power, durability, and operator safety.
