JET JBG-10A Applications
- Heavy material removal, weld blending, and structural steel conditioning
- High-volume tool sharpening for industrial blades, heavy chisels, and lathe tools
- Snagging, smoothing, and deburring rough metal castings
- Everyday, continuous-duty metalworking in demanding commercial shops
Ideal for industrial fabricators and professional toolrooms needing a high-torque, low-RPM grinding solution that fits efficiently into tight shop layouts.
JET JBG-10A Specifications
| Stock Number | JT9-577103 |
|---|---|
| Model Number | JBG-10B |
| Electrical | 115V, Single Phase (1Ph) |
| Maximum Speed | 1,725 RPM |
| Wheel Size (Diameter x Width) | 10" x 1" |
| Shaft / Arbor Hole Diameter | 1" |
| Included Wheel Grits | 24 Grit (Coarse) / 46 Grit (Medium) |
| Overall Dimensions (L x W x H) | 25" x 16" x 15" |
| Net Weight / Gross Weight | 108.0 lbs / 110.0 lbs |
| Warranty | JET 2-Year Warranty |
JET JBG-10A Performance & Construction
- Optimized 1,725 RPM operational speed delivers immense torque while running cooler, preventing thermal damage to expensive hardened steel tools.
- Cast iron wheel guards and dust vents ensure maximum operator safety while efficiently managing heavy grinding debris.
- Totally enclosed, pre-lubricated ball bearings protect the internal motor components from highly abrasive metallic dust, extending the lifespan of the machine.
- 24 and 46 grit vitrified grinding wheels included so you are fully equipped for rapid stock reduction and edge refining right out of the box.
- Adjustable tool rests provide rock-solid support for precise angling and safe material handling.
- One-piece quick adjusting spark guards make it fast and easy to maintain optimal safety clearances as the wheels wear down.
- Heavy-duty guarded toggle switch provides reliable power control and withstands the physical abuse of a busy shop.
Why Choose the JET JBG-10A Bench Grinder
- Massive 10-inch wheel capacity handles oversized stock and heavy tools with ease.
- Low-RPM configuration protects edge tempers while chewing through raw metal.
- Rigid cast iron construction absorbs vibration to deliver flawlessly smooth finishes.
- Backed by the reliable JET Red Assurance 2-Year Warranty.
The JET JBG-10A is a heavy-duty workhorse that brings true industrial grinding capacity into a space-efficient benchtop footprint.
