JET IBG-10SSB Applications
- High-gloss polishing, buffing, and mirror-finishing on oversized metal components
- Heavy-duty edge blending, deburring, and detailed part surface conditioning
- Continuous-duty industrial production, automotive restoration, and aerospace finishing
- Custom polishing arrays utilizing a wide selection of wide-profile specialty finishing wheels
Ideal for industrial manufacturing facilities, professional metal shops, and restoration hubs that require absolute rigidity and consistent high-torque performance on large parts.
JET IBG-10SSB Specifications
| Stock Number | JT9-578410 |
|---|---|
| Model Number | IBG-10SSB |
| Motor Power | 1-1/2 HP, 1-Phase (1Ph) |
| Electrical Input | 115V / 230V Dual Voltage Capability |
| Motor Amps | 15A |
| Maximum Speed | 1,800 RPM |
| Wheel Diameter | 10" |
| Shaft / Arbor Diameter | 1" |
| Overall Dimensions (L x W x H) | 30" x 9-11/16" x 15-5/8" |
| Net Weight / Gross Weight | 72.0 lbs / 80.0 lbs |
| Compliance & Warranty | CSA/CUS Certified • JET 2-Year Warranty |
JET IBG-10SSB Performance & Construction
- Heavy Cast Iron Bases supply maximum structural mass to absorb operational harmonics and ensure glass-smooth tracking.
- Oversized 1-inch motor shafts, heavy retainer plates, and massive lock nuts provide bulletproof support for heavy, wide buffing wheels.
- Flexible spacer design architecture offers a wide range of options allowing you to safely deploy a massive variety of specialized finishing and buffing wheels.
- Safety switch with removable key protects busy industrial workspaces by preventing unauthorized machine use or accidental start-ups.
- Totally enclosed, pre-lubricated ball bearings prevent fine polishing compounds and metal dust from entering the motor core, ensuring maintenance-free performance.
Why Choose the JET IBG-10SSB Industrial Buffer
- Massive 10-inch platform combined with a 1-1/2 HP motor delivers uncompromising industrial torque.
- Controlled 1,800 RPM speed protects delicate material profiles and edge tempers from severe friction heat.
- Rugged cast iron construction ensures lifelong durability on high-output production lines.
- Backed by the industry-leading JET Red Assurance 2-Year Warranty.
The JET IBG-10SSB sets the commercial benchmark for heavy-part polishing cells, blending extreme structural mass with precision torque output.
