Milling Machine Applications
- Heavy material removal, face milling, and wide profiling supported by the rigid 10" x 50" work table.
- Consistent, high-efficiency production runs leveraging the included X and Y-axis powerfeeds to optimize chip loads and surface finish.
- Highly precise deep-hole drilling and Z-axis boring utilizing the quill-mounted 3-Axis ACU-RITE digital readout.
- Rigid toolroom tasks demanding tight tolerances, maintained by high-precision Class 7 spindle bearings and chromed lead screws.
Engineered for immediate deployment on busy fabrication floors, this fully equipped package drastically reduces operator fatigue and manual layout time, accelerating your shop's daily throughput.
Technical Specifications
| Stock Number | JT9-690159 (Model JTM-1050VS2) |
|---|---|
| Machine Type | Variable Speed Vertical Knee Mill |
| Motor Power | 3.00 HP |
| Electrical Configuration | 230V / 460V, Three-Phase (3Ph) |
| Spindle Speed Control | Variable Speed Pulley Drive |
| Spindle Speed Range | 70 RPM Minimum – 3,800 RPM Maximum |
| Spindle Taper Size | R-8 (1/8" - 7/8" Collet Capacity) |
| Table Dimensions (L x W) | 50" x 10" (2-1/2" T-Slot Centers) |
| Work Table Load Capacity | 720 lbs |
| Axis Travels | Longitudinal (X): 35" • Cross (Y): 15-1/4" • Knee (Z): 14-1/4" • Ram: 20-1/2" |
| Quill Properties | 3-3/8" Chromed Diameter • 5" Spindle Travel |
| Max Spindle to Table Distance | 19" |
| Included System Upgrades | 3-Axis ACU-RITE 203 DRO (Quill) • X & Y Powerfeeds • Tolerance Test Sheet |
| Overall Dimensions (L x W x H) | 96" x 78" x 88" (Gross Weight: 2,900 lbs) |
Performance & Integration Features
- 3-Axis ACU-RITE 203 DRO: A pre-installed premium digital readout system, uniquely configured to track quill travel, allowing for unparalleled precision during boring and plunging operations.
- Dual-Axis Powerfeeds: Automated X and Y-axis travel drastically cuts down on manual cranking, yielding smoother cuts, longer tool life, and reduced operator strain.
- Hardened Square Vertical Knee Ways: Designed to offer significantly more contact surface area than dovetail ways, delivering immense rigidity and minimizing deflection during heavy cuts.
- Class 7 Spindle Bearings: Ultra-precision bearings support the internally cooled spindle head, ensuring exceptional concentricity and heat dissipation over long shifts.
- Chrome Lead Screws: Both the X and Y axes utilize highly durable chrome-plated lead screws, paired with adjustable gibs, for smooth, wear-resistant traversing.
- Built-In Coolant Base: The main casting base features an internal coolant tank ready for an aftermarket flood coolant pump system to handle high-temperature materials.
- One-Shot Lubrication System: Quickly and efficiently distributes critical oil to the ways and leadscrews, protecting the machine's geometric accuracy with zero hassle.
Why Invest in This JET Mill Package
- Delivers a perfect middle-ground for shops needing more capacity than a 9x49 mill, providing a robust 10x50 table and a 720 lb load limit.
- Eliminates the downtime and labor costs associated with sourcing and installing aftermarket DROs and powerfeeds—it's ready to work right off the pallet.
- The heavy-duty motor drive with chrome-plated bearing supports guarantees unyielding power transfer directly to the R-8 cutting tool.
- Backed by the industry-leading JET RED ASSURANCE 2-Year Warranty and strict quality control standards.
This JTM-1050VS2 package is a top-tier choice for professional machinists, perfectly balancing robust mechanical mass with industry-standard digital control and automation.
