Gibraltar Arbor Press 805-10402 Applications
- Bearing installation and removal
- Bushing, pin, and shaft press fitting
- Metal staking and riveting operations
- Small broaching applications
- Assembly and production workstations
- Toolrooms and maintenance departments
- Machine shops and fabrication facilities
- General industrial pressing and repair work
The 4-ton capacity and long ram stroke make this arbor press ideal for precision assembly, component installation, and maintenance tasks requiring controlled manual force.
Gibraltar Arbor Press 805-10402 Specifications
| Model | 805-10402 |
|---|---|
| Pressure Capacity | 4 Ton (4 t) |
| Ram Diameter | 1-3/4 in. |
| Throat Depth | 8-3/8 in. |
| Ram Stroke | 16-3/4 in. |
| Maximum Work Height | 15-3/4 in. |
| Maximum Work Width/Diameter | 20 in. |
| Leverage Style | Single Lever |
| Leverage Ratio | 20:1 |
| Base Width | 10.00 in. |
| Base Depth | 10.25 in. |
| Table Width | 10.00 in. |
| Table Length | 9.75 in. |
| UNSPSC | 23251500 |
| Country of Origin | China |
Gibraltar Arbor Press 805-10402 Features & Performance
- 4-ton pressing capacity provides ample force for pressing bearings, bushings, pins, gears, and other mechanical components.
- Heavy-duty cast iron frame delivers exceptional rigidity and strength for long-term industrial use while minimizing deflection under load.
- Large 1-3/4-inch precision ram offers excellent stability and controlled force transfer during pressing operations.
- 20:1 leverage ratio multiplies operator input, allowing heavy pressing tasks to be completed with reduced effort.
- Extended 16-3/4-inch ram stroke accommodates taller workpieces and increases versatility across a wide range of applications.
- 8-3/8-inch throat depth provides generous clearance for larger components and off-center pressing operations.
- 15-3/4-inch maximum work height supports a broad variety of fixtures, tooling, and assembled components.
- Stable 10-inch square base offers excellent support during heavy pressing operations while promoting consistent accuracy.
- Manual single-lever operation gives operators precise control for delicate assembly work and high-force industrial applications.
- Ideal for continuous shop use in manufacturing, repair facilities, fabrication shops, maintenance departments, and production environments.
Why Choose the Gibraltar Arbor Press 805-10402
- Heavy-duty 4-ton capacity for demanding industrial pressing applications.
- Large ram and long stroke accommodate a wide variety of workpieces.
- 20:1 leverage ratio provides excellent mechanical advantage with minimal operator effort.
- Rigid cast iron construction ensures long-lasting durability and dependable performance.
- Perfect for bearing installation, broaching, riveting, staking, assembly, and maintenance operations.
- Reliable manual arbor press built for professional machine shops and industrial manufacturing facilities.
Shipping Notice: This item ships via truck due to its size and weight.
