Euroboor TUBE.200S/T Applications
- Large diameter pipe drilling and tapping operations
- Industrial pipe construction and fabrication
- Structural steel and heavy metal fabrication
- Maintenance work on pipelines and industrial installations
- Metalworking environments requiring high-capacity annular drilling
Designed for demanding drilling applications on large pipes and tubes where high torque, precision control, and strong magnetic stability are essential.
Euroboor TUBE.200S/T Specifications
| Machine Type | Magnetic Drilling Machine |
|---|---|
| Maximum Annular Cutter Diameter | 7 7/8" (200 mm) |
| Maximum Tapping Capacity | M48 (1 7/8") |
| Rotation Direction | Bidirectional (Right / Left) |
| Motor Power | 2,800 W |
| Power Supply Voltage | 110 – 120 Volt |
| Power Supply Frequency | 60 Hertz |
| Power Supply Connection | NEMA 5-15 Plug |
| Spindle Type | MT4 Morse Taper |
| Gearbox | 4-Speed Oil Lubricated Gearbox |
| Minimum Pipe Diameter | 9 7/16" (240 mm) |
| Minimum Material Thickness | 1/8" (3.5 mm) |
| Magnetic Force | 5,280 lbs |
| Weight | 162 lbs |
Euroboor TUBE.200S/T Performance & Safety Features
- Brushless Motor Technology provides higher efficiency, longer lifespan, and reduced internal wear.
- Heavy-Duty 4-Speed Oil Lubricated Gearbox ensures smooth operation and reliable power transfer.
- Electronic Adjustable Speed Control allows precise matching of drilling speed to cutter diameter and material.
- Right / Left Rotation supports tapping operations and controlled drilling performance.
- Pivoting Permanent Magnet enables secure mounting on curved pipe surfaces and flat materials.
- Digital Display provides clear operational feedback and machine status during drilling.
- GYRO-TEC Safety System automatically shuts down the machine in case of sudden movement or excessive vibration.
- Advanced Electronic Protection helps prevent overload, power fluctuation damage, and overheating.
- Integrated Cooling & Lubrication System improves drilling efficiency and extends cutter lifespan.
Package Contents
- 1 × Metal storage case
- 1 × Euroboor TUBE.200S/T Magnetic Drilling Machine
- 3 × Capstan hub handles
- 1 × Spindle holder MT4 – Weldon 1 1/4" (31.75 mm) with cooling/lubrication ring
- 1 × Spindle holder MT3 – Weldon 3/4" (19.05 mm) with cooling/lubrication ring
- 1 × Morse taper reducing adapter MT4 → MT3
- 1 × Drift key
- 1 × Lubrication / cooling system
- 1 × Allen key 3/32" (2.5 mm)
- 1 × Allen key 13/64" (5 mm)
- 1 × Allen key 14/64" (6 mm)
- 1 × Safety chain
- 1 × Ear protection
- 1 × Safety goggles
- 1 × Safety gloves
- 1 × User manual
Why Choose the Euroboor TUBE.200S/T Magnetic Drilling Machine
- Extreme drilling capacity up to 7 7/8" (200 mm)
- Heavy-duty 2,800 W motor designed for industrial applications
- Secure pipe mounting with pivoting permanent magnetic base
- Brushless motor technology for efficiency and durability
- Advanced electronics and GYRO-TEC safety system for safe operation
- Ideal for pipe fabrication, maintenance, and structural metalwork
The Euroboor TUBE.200S/T Magnetic Drilling Machine is engineered for professionals who require maximum drilling capacity, precision control, and reliable performance when working on large pipe constructions and demanding metalworking projects.
