Euroboor ELM.1000 Lifting Magnet Applications
- Lifting heavy steel plates and thick metal sheets
- Handling large steel pipes and round tubular materials
- Moving structural steel beams and fabricated components
- Material handling in heavy fabrication workshops
- Steel processing and manufacturing operations
- Safe positioning and loading of large ferrous workpieces
The Euroboor ELM.1000 Lifting Magnet provides a powerful and reliable lifting solution for moving heavy steel materials without chains, slings, or external power sources.
Euroboor ELM.1000 Lifting Magnet Specifications
| Product Name | Euroboor ELM.1000 Lifting Magnet |
|---|---|
| Lifting Capacity (Flat Material) | 1000 kg (2000 lbs) |
| Lifting Capacity (Round Material) | 500 kg (1000 lbs) |
| Safety Factor | 3.5 : 1 |
| Length | 336 mm (13 1/4") |
| Width | 148 mm (5 13/16") |
| Height | 234 mm (9 3/16") |
| Eye Width | 52 mm |
| Weight | 43 kg (94.8 lb) |
| Minimum Plate Thickness | 40 mm (1 37/64") |
| Round Material Diameter Range | 150 – 380 mm |
| Maximum Operating Temperature | 80°C / 176°F |
| Application | Lifting |
Euroboor ELM.1000 Lifting Magnet Performance & Construction
- Extremely powerful permanent magnet system enables safe lifting of very heavy steel components without external power.
- 1000 kg lifting capacity for flat materials supports handling of large steel plates and heavy workpieces.
- 500 kg lifting capacity for round materials allows safe lifting of large pipes and cylindrical steel objects.
- High safety factor of 3.5 ensures secure lifting operations and increased workplace safety.
- Suitable for rough or finished surfaces without damaging the material.
- Maintenance-free magnetic system minimizes downtime and operating costs.
- Reliable and consistent performance even under extreme industrial working conditions.
- Simple and ergonomic operation allows quick activation and release of the magnetic lifting force.
Euroboor ELM.1000 Lifting Magnet Package Contents
- 1 × Euroboor ELM.1000 Lifting Magnet
- 1 × Allen Key 5 mm (13/64")
- 1 × Test Certificate
- 1 × User Manual
Each Euroboor ELM.1000 Lifting Magnet is individually tested and supplied with a certificate verifying the lifting capacity and safety compliance of the unit.
Why Choose the Euroboor ELM.1000 Lifting Magnet
- Ultra heavy-duty magnetic lifter for industrial steel handling.
- 1000 kg lifting capacity for flat materials and 500 kg for round materials.
- 3.5 safety factor ensures secure and reliable lifting.
- Maintenance-free permanent magnet system.
- Suitable for flat plates and tubular steel objects.
- Individually tested and delivered with a safety certificate.
The Euroboor ELM.1000 Lifting Magnet is the most powerful magnetic lifter in the Euroboor lifting range, designed to safely move extremely heavy steel components in demanding fabrication and industrial environments.
