Ebac RM40-SH Dehumidifier 11186SH-US Applications
- Industrial workshops and equipment rooms
- Basements and crawl spaces
- Warehouses and storerooms
- Garages and vehicle storage areas
- Mechanical and electrical service rooms
- Remote installations requiring gravity drainage
The compact footprint and rugged construction of the Ebac RM40-SH Dehumidifier 11186SH-US make it an excellent solution for environments where reliable humidity control is essential to protect equipment, tools, and building structures.
Ebac RM40-SH Dehumidifier 11186SH-US Specifications
| Model | RM40-SH |
|---|---|
| Part Number | 11186SH-US |
| Voltage Requirement | 110V / 1 Phase / 60 Hz |
| Power Consumption | 0.344 kW |
| Current Draw | 3.3 A |
| Typical Moisture Extraction | 24 Pints per Day |
| Airflow | 100 CFM |
| Noise Level | 47 dBA |
| Refrigerant | R454c |
| Effective Coverage Volume | 3,000 cu.ft. |
| Minimum Operating Temperature | 33°F |
| Maximum Operating Temperature | 95°F |
| Height | 12 in |
| Width | 13 in |
| Depth | 22 in |
| Weight | 50 lbs |
| Compressor Type | Rotary |
Ebac RM40-SH Dehumidifier 11186SH-US Performance & Construction
- Integral Humidistat automatically controls humidity levels by cycling the unit on and off.
- High Efficiency Rotary Compressor ensures reliable moisture removal and energy-efficient performance.
- Epoxy Powder Coated Steel Construction provides superior durability and corrosion resistance.
- Hot Gas Temperature Sensitive Defrost technology prevents frost buildup and maintains performance in cooler conditions.
- Simple Installation and Operation allows quick setup with minimal maintenance requirements.
- Rugged Military Style Handles provide durable grip points for easy handling and installation.
- 1/2” Gravity Drain Connection supports continuous operation with permanent drainage.
- Rubber Anti-Vibration Feet reduce noise and protect installation surfaces.
- Epoxy Powder Coated Chassis increases long-term resistance to harsh environments.
- Optional Wall Mounting Bracket allows the unit to be mounted off the floor to save space.
Ebac RM40-SH Dehumidifier 11186SH-US Dehumidification Process
- Air is drawn into the Ebac RM40-SH Dehumidifier 11186SH-US by an internal fan.
- The air passes across a cold evaporator coil where moisture condenses.
- Condensed moisture collects and drains away through the gravity drain connection.
- The air then passes through the condenser coil where heat energy is recovered.
- The discharged air returns to the room slightly warmer but significantly drier.
- Continuous circulation gradually reduces humidity levels throughout the space.
- An automatic defrost system protects the coils during colder conditions.
- The internal humidistat cycles the unit automatically to maintain the desired humidity level.
The refrigeration-based drying system used by the Ebac RM40-SH Dehumidifier 11186SH-US efficiently removes excess moisture while maintaining consistent industrial performance.
Ebac RM40-SH Dehumidifier 11186SH-US Included Components
- 1 × RM40-SH Dehumidifier
- 1 × RM40-SH Owner’s Manual
- 1 × 3/8" ID PVC Tube (3 m Long)
- 1 × Jubilee Clip
Why Choose the Ebac RM40-SH Dehumidifier 11186SH-US
- Removes up to 24 pints of moisture per day for effective humidity control.
- Durable epoxy-coated steel construction designed for industrial environments.
- Integrated humidistat provides automatic humidity management.
- Gravity drain system allows continuous unattended operation.
- Compact footprint ideal for basements, workshops, and equipment rooms.
- Optional wall mounting bracket saves valuable floor space.
The Ebac RM40-SH Dehumidifier 11186SH-US provides compact industrial performance, reliable moisture removal, and durable construction for environments where humidity protection is critical.
