Ebac CS60 Dehumidifier 11264CS-US Applications
- Commercial offices and laboratories
- Warehouses and storage facilities
- Restaurants, bars, and hospitality environments
- Museums and archival storage rooms
- Computer and telecommunications rooms
- Locker rooms and basements
- Crawl spaces and confined installations
The Ebac CS60 Dehumidifier 11264CS-US is designed to eliminate excess humidity that can cause condensation, mold growth, corrosion, and costly damage to equipment or stored materials.
Ebac CS60 Dehumidifier 11264CS-US Specifications
| Model | CS60 |
|---|---|
| Part Number | 11264CS-US |
| Power Requirement | 110V / 1 Phase / 60 Hz |
| Power Consumption | 880 W |
| Current Draw | 7 A |
| Typical Moisture Extraction | 56 Pints per Day |
| Airflow | 147 CFM |
| Noise Level | 57 dBA |
| Refrigerant | R454c |
| Effective Coverage Volume | 8,370 cu.ft. |
| Minimum Operating Temperature | 33°F |
| Maximum Operating Temperature | 95°F |
| Height | 15 in |
| Width | 14 in |
| Depth | 20 in |
| Weight | 63 lbs |
| Compressor Type | Rotary |
Ebac CS60 Dehumidifier 11264CS-US Performance & Construction
- Adjustable Control Humidistat maintains the desired level of dryness automatically.
- High Efficiency Rotary Compressor ensures strong moisture extraction while keeping operating costs low.
- Hot Gas Defrost Technology automatically melts frost buildup to maintain performance at lower ambient temperatures.
- Electronic Defrost Control ensures efficient operation across varying environmental conditions.
- Convenient Condensate Drain Connection allows easy attachment of a drain hose for continuous operation.
- Epoxy Powder-Coated Steel Chassis provides durability and corrosion resistance for industrial environments.
- Collapsible Carrying Handles allow easier transport and positioning of the unit.
- Rubber Anti-Vibration Feet minimize noise and vibration transmission.
- Washable Air Filter helps maintain airflow efficiency while simplifying maintenance.
- Standard 115V Plug allows simple installation without special electrical requirements.
Ebac CS60 Dehumidifier 11264CS-US Dehumidification Process
- Air is drawn into the Ebac CS60 Dehumidifier 11264CS-US by a high-efficiency fan.
- The air passes across a cold evaporator coil where moisture condenses.
- Condensed water collects in the condensate tray and drains through the drain connection.
- The air then passes through the condenser coil where recovered heat slightly warms the air.
- The discharged air returns to the room warmer and significantly drier.
- Continuous circulation gradually lowers the humidity level in the controlled space.
- The automatic defrost system prevents frost buildup during cooler operation.
- The internal humidistat cycles the system automatically to maintain the selected humidity level.
Using an efficient refrigeration-based drying process, the Ebac CS60 Dehumidifier 11264CS-US delivers consistent moisture removal while maintaining energy-efficient performance.
Ebac CS60 Dehumidifier 11264CS-US Included Components
- 1 × CS60 Dehumidifier
- 1 × CS60 Owner’s Manual
- 1 × 3/8" ID PVC Tube (3 m Long)
- 1 × Jubilee Clip
Why Choose the Ebac CS60 Dehumidifier 11264CS-US
- High capacity removal of up to 56 pints of moisture per day.
- Energy-efficient rotary compressor for lower operating costs.
- Compact design capable of controlling humidity in spaces up to 8,370 cubic feet.
- Automatic humidistat ensures consistent humidity control.
- Durable industrial construction for long-term reliability.
- Simple installation with standard plug-and-play operation.
The Ebac CS60 Dehumidifier 11264CS-US provides powerful commercial-grade moisture control in a compact package, making it an excellent solution for facilities that require reliable humidity management and long-term durability.
