Ebac CD30-SE Dehumidifier 11420GS-US Applications
- Industrial pump stations and pipe galleries
- Marine vessels and offshore equipment compartments
- Electrical control rooms and mechanical equipment areas
- Crawl spaces and confined structural cavities
- Warehouses, workshops, and manufacturing facilities
- Remote installations requiring humidity monitoring
- Permanent installations with wall-mounted configuration
The Ebac CD30-SE Dehumidifier 11420GS-US is engineered for installations where continuous moisture control and remote humidity monitoring are critical for protecting infrastructure and equipment.
Ebac CD30-SE Dehumidifier 11420GS-US Specifications
| Model | CD30-SE |
|---|---|
| Part Number | 11420GS-US |
| Power Requirement | 110V / 1 Phase / 60 Hz |
| Power Consumption | 480 W |
| Current Draw | 4 A |
| Typical Moisture Extraction (80°F / 60% RH) | 24 Pints per Day |
| Extraction @ 65°F / 60% RH | 15 Pints per Day |
| Efficiency @ 80°F / 60% RH | 1.83 L/kW |
| Efficiency @ 65°F / 60% RH | 1.35 L/kW |
| Airflow | 88 CFM |
| Noise Level | 47 dBA |
| Refrigerant | R290 |
| Effective Coverage Volume | 3,000 cu.ft. |
| Minimum Operating Temperature | 33°F |
| Maximum Operating Temperature | 95°F |
| Height | 12 in |
| Width | 12 in |
| Depth | 22 in |
| Weight | 50 lbs |
| Compressor Type | Reciprocating |
Ebac CD30-SE Dehumidifier 11420GS-US Monitoring & Control Features
- Status Indicators provide quick visual confirmation of operational status.
- Adjustable Alarm Humidistat allows facilities to preset humidity thresholds for monitoring.
- Voltage Free Alarm Signal enables integration with remote monitoring systems or building automation systems.
- Power On Indicator clearly shows when the unit is actively operating.
- Hours Run Meter tracks operational time for maintenance scheduling.
- Wall Mounting Bracket allows convenient permanent installation in equipment rooms and service spaces.
- Heavy-Duty Industrial Construction ensures reliable performance in harsh environments.
- Hot Gas Defrost Technology maintains efficient operation in lower temperature conditions.
Ebac CD30-SE Dehumidifier 11420GS-US Dehumidification Process
- Air is drawn into the Ebac CD30-SE Dehumidifier 11420GS-US by an internal fan.
- The air passes across a cold evaporator surface where moisture condenses.
- Condensed moisture collects and drains away through the gravity drain system.
- The cooled air then passes through the condenser where heat energy is recovered.
- The discharged air returns to the room slightly warmer but significantly drier.
- Continuous air circulation gradually lowers the overall humidity within the controlled area.
- An automatic defrost system protects the coils during colder conditions.
- The internal humidistat cycles the unit on and off to maintain the desired humidity level efficiently.
Using a refrigeration-based moisture removal process, the Ebac CD30-SE Dehumidifier 11420GS-US efficiently reduces humidity while maintaining reliable performance in industrial environments.
Ebac CD30-SE Dehumidifier 11420GS-US Included Components
- 1 × CD30-SE Static Dryer
- 1 × CD30-SE Owner’s Manual
- 1 × Wall Mounting Bracket
- 1 × 12 mm ID PVC Drain Tube (3 m Long)
- 1 × Jubilee Clip
- 3 × Brass Wood Screws
- 3 × Rawl Plugs
Why Choose the Ebac CD30-SE Dehumidifier 11420GS-US
- Removes up to 24 pints of moisture per day under standard operating conditions.
- Integrated monitoring features for remote humidity supervision.
- Designed for industrial, marine, and infrastructure environments.
- Wall-mount installation option for space-efficient setups.
- Heavy-duty steel construction for long service life.
- Efficient moisture control for spaces up to 3,000 cubic feet.
The Ebac CD30-SE Dehumidifier 11420GS-US combines durable industrial construction, advanced monitoring capabilities, and efficient humidity removal to protect equipment, structures, and materials from damaging moisture conditions.
