Ebac CD30-S Dehumidifier 11420GY-US Applications
- Industrial pump stations and pipe galleries
- Marine environments and shipboard equipment rooms
- Crawl spaces and confined structural cavities
- Warehouses, workshops, and factory environments
- Electrical, electronic, and mechanical equipment rooms
- Remote installations requiring reliable humidity control
- Portable moisture control between job sites
The compact design and strong performance of the Ebac CD30-S Dehumidifier 11420GY-US make it ideal for smaller spaces where excess humidity can cause corrosion, mold growth, structural damage, and equipment failure.
Ebac CD30-S Dehumidifier 11420GY-US Specifications
| Model | CD30-S |
|---|---|
| Part Number | 11420GY-US |
| Power Requirement | 110V / 1 Phase / 60 Hz |
| Power Consumption | 480 W |
| Current Draw | 4 A |
| Typical Moisture Extraction (80°F / 60% RH) | 24 Pints per Day |
| Extraction @ 65°F / 60% RH | 15 Pints per Day |
| Efficiency @ 80°F / 60% RH | 1.83 L/kW |
| Efficiency @ 65°F / 60% RH | 1.35 L/kW |
| Airflow | 88 CFM |
| Noise Level | 47 dBA |
| Refrigerant | R290 |
| Effective Coverage Volume | 3,000 cu.ft. |
| Minimum Operating Temperature | 33°F |
| Maximum Operating Temperature | 95°F |
| Height | 12 in |
| Width | 12 in |
| Depth | 22 in |
| Weight | 50 lbs |
| Compressor Type | Reciprocating |
Ebac CD30-S Dehumidifier 11420GY-US Performance & Construction
- Adjustable Control Humidistat allows precise humidity regulation to maintain desired environmental conditions.
- EIP Hot Gas Temperature Sensitive Defrost system ensures reliable operation in cooler environments by automatically preventing frost build-up on coils.
- Convenient Drain System with gravity drain outlet for continuous moisture removal.
- Totally Enclosed Coils help protect critical components from dust, debris, and damage in harsh environments.
- Heavy Gauge Steel Case provides superior durability for demanding industrial and marine installations.
- Sturdy Carrying Handles allow easy transportation between job sites and installation locations.
- Electronic Defrost Control and temperature-sensitive defrost ensure dependable performance across varying environmental conditions.
- Rubber Feet for Free Standing Installation help reduce vibration while protecting flooring surfaces.
- Epoxy Powder Coating enhances corrosion resistance for long-term reliability.
- Gravity Drain Outlet (1/2" ID) supports permanent drainage installations.
Ebac CD30-S Dehumidifier 11420GY-US Dehumidification Process
- Air is drawn into the Ebac CD30-S Dehumidifier 11420GY-US by a high-efficiency internal fan.
- The air passes across a cold evaporator surface where moisture condenses.
- Condensed water collects and drains away through the condensate outlet.
- The dried air passes through the condenser where heat energy is recovered.
- The air exits the unit slightly warmer but significantly drier than before.
- Continuous air circulation gradually reduces humidity throughout the controlled space.
- The automatic defrost system protects the unit during cooler operating conditions.
- The internal humidistat cycles the unit on and off to maintain the selected humidity level while conserving energy.
By using a refrigeration-based moisture removal process, the Ebac CD30-S Dehumidifier 11420GY-US delivers efficient and reliable humidity control for demanding industrial environments.
Ebac CD30-S Dehumidifier 11420GY-US Included Components
- 1 × CD30-S Static Dryer Unit
- 1 × CD30-S Owner’s Manual
- 1 × 12 mm ID PVC Drain Tube (3 m Long)
- 1 × Jubilee Clip
Why Choose the Ebac CD30-S Dehumidifier 11420GY-US
- Removes up to 24 pints of moisture per day under typical operating conditions.
- Built for harsh industrial and marine environments.
- Compact design suitable for crawl spaces and tight mechanical areas.
- Hot gas defrost technology ensures reliable cold-temperature performance.
- Heavy-duty steel construction for long service life.
- Energy-efficient humidity control for spaces up to 3,000 cubic feet.
The Ebac CD30-S Dehumidifier 11420GY-US delivers durable, efficient, and dependable humidity control for industrial facilities, equipment rooms, crawl spaces, and marine installations where moisture protection is essential.
