Ebac CD220-D Dehumidifier Applications
- Warehouses and industrial storage facilities
- Factories and manufacturing plants
- Commercial offices and medium-scale buildings
- Basements and moisture-sensitive storage areas
- Production environments requiring humidity control
- Ducted HVAC or standalone humidity management systems
Designed to efficiently control humidity in medium to large spaces without the need for multiple smaller dehumidifiers.
Ebac CD220-D Dehumidifier Specifications
| Model | CD220-D |
|---|---|
| Part Number | 11181GR-US |
| Typical Extraction | 157 Pints / Day |
| Effective Coverage | 600 m³ |
| Voltage | 220V / 1 Phase / 60 Hz |
| Power Consumption | 2.3 kW |
| Current | 11 A |
| Airflow (Low Speed) | 585 CFM |
| Airflow (High Speed) | 664 CFM |
| Noise Level | 73 dBA |
| Refrigerant | R32 |
| Minimum Operating Temperature | 33°F |
| Maximum Operating Temperature | 95°F |
| Height | 32.7" |
| Width | 29.5" |
| Depth | 17.5" |
| Weight | 176 lbs |
Ebac CD220-D Performance & Construction
- High Capacity Moisture Removal – Removes up to 157 pints of moisture per day for reliable humidity control.
- Digital Humidistat Control – Adjustable electronic humidistat maintains precise humidity levels automatically.
- Reverse Cycle Defrost Technology – EIPL’s temperature sensitive defrost system prevents frost buildup and maintains performance at low temperatures.
- Two-Speed Centrifugal Fan – Quiet operation with high airflow performance for efficient air circulation.
- Integral Condensate Pump – High capacity pump allows convenient automatic drainage.
- Remote Humidistat Facility – Allows humidity sensing and control from a remote location.
- Heavy Duty Steel Construction – Epoxy powder-coated steel cabinet protects internal components and ensures long service life.
- Adjustable Feet – Simplifies installation and leveling on uneven surfaces.
- Optional Duct Connections – May be ducted to integrate with HVAC or existing ventilation systems.
- Washable Air Filter – Easy maintenance and improved air quality.
How the Ebac CD220-D Dehumidifier Works
- Moist air is drawn into the unit by a high efficiency fan.
- The air passes across the cold evaporator coil.
- Moisture condenses from the air as it cools.
- Collected water drains into the condensate tray.
- An internal pump removes water through the drain tube.
- The air then passes through the condenser coil.
- The air is reheated and returned to the room slightly warmer and significantly drier.
- The defrost system automatically removes frost buildup when required.
- The humidistat automatically cycles the unit on and off to maintain the desired humidity level.
What’s Included
- 1 × Ebac CD220-D Industrial Dehumidifier
- 1 × Owner’s Manual
- 1 × 3/8" ID PVC Drain Tube – 7.8 m
- 1 × Quick Release Tube Connector
Why Choose the Ebac CD220-D Dehumidifier
- 157 PPD high capacity moisture removal
- Coverage for large areas up to 600 m³
- Reverse cycle defrost for low temperature operation
- Quiet two-speed centrifugal fan system
- Heavy duty steel construction for industrial environments
- Flexible installation with optional ducting
The Ebac CD220-D Industrial Dehumidifier delivers powerful moisture removal, energy-efficient operation, and rugged construction, making it an ideal solution for controlling humidity in warehouses, factories, and large commercial environments.
