Denray 9600 Tube Filtration Applications
- Large woodworking and sanding operations
- Cabinet and furniture manufacturing facilities
- Architectural millwork production
- Production sanding and finishing departments
- Large panel, tabletop, and door sanding applications
- Multi-operator workstations requiring expanded workspace
- Custom woodworking and fabrication environments
- Collection of fine airborne wood dust generated during sanding and finishing operations
Ideal for facilities that need an oversized sanding workstation capable of supporting multiple projects simultaneously while maintaining exceptional dust collection performance.
Denray 9600 Tube Filtration Specifications
| Model | 9600 Tube Filtration |
|---|---|
| Work Surface Size | 96" × 48" |
| Overall Height | 36" |
| Weight | 930 lbs |
| Motor | 3 HP |
| Fan Diameter | 18" |
| Airflow Capacity | 4,300 CFM |
| Sound Level | 81 dB |
| Filtration System | 30 Tube Filters |
| Filtration Efficiency | 99% Capture Rate at 1 Micron |
| Mobility | Integrated Casters |
| Electrical Receptacles | 4 Receptacles |
Denray 9600 Tube Filtration Electrical Requirements
| Configuration | Voltage | Amperage |
|---|---|---|
| Single Phase | 220V | 11.8 Amps |
| Three Phase | 230V | 8.2 Amps |
| Three Phase | 460V | 4.1 Amps |
| Three Phase | 575V | 3.4 Amps |
Denray 9600 Tube Filtration Performance & Construction
- 99% Filtration Efficiency at 1 Micron captures fine airborne wood dust before it can circulate throughout the facility, helping maintain a cleaner work environment.
- Advanced Tube Filtration Technology delivers superior filtration performance compared to traditional pleated filter systems while maintaining strong airflow and efficient dust collection.
- 30 High-Efficiency Tube Filters provide an enormous filtration surface area that maximizes dust capture and supports long-term filtration performance.
- Powerful 4,300 CFM Airflow Capacity creates strong downward airflow across the entire workstation, effectively capturing dust directly at the source.
- Large 18-Inch Industrial Fan generates dependable suction and airflow for demanding industrial sanding and finishing operations.
- Massive 96" × 48" Work Surface accommodates oversized projects and allows multiple operators to work simultaneously on separate tasks.
- Manual Filter Cleaning System includes a filter cleaning brush and handle for quick maintenance and continued filtration efficiency.
- Rubber-Coated Tabletop helps protect finished workpieces from scratches while providing a durable, slip-resistant working surface.
- Four Integrated Receptacles provide convenient power access for multiple tools and accessories directly at the workstation.
- Heavy-Duty Steel Construction is designed for continuous industrial operation and long-term durability.
- Integrated Casters allow flexible workstation placement and mobility within changing production environments.
Denray 9600 Tube Filtration Available Options
- Explosion Proof Motor (Three-Phase Models Only)
- Light Bar
- Muffler Package (Reduces Sound Levels by Approximately 10–12 dB)
- Three-Sided Hinged Safety Shield
- HDPE Plastic Tabletop Upgrade
- Larger Motor and Fan Upgrade Package
Optional upgrades allow the Denray 9600 Tube Filtration to be customized for specialized applications, enhanced operator safety, quieter operation, and increased airflow performance.
Why Choose the Denray 9600 Tube Filtration
- Designed for large woodworking projects and multi-operator sanding stations.
- 99% filtration efficiency at 1 micron for exceptional airborne dust capture.
- Advanced tube filtration technology outperforms many traditional pleated filter systems.
- Powerful 4,300 CFM airflow captures dust directly at the source.
- Massive 96" × 48" work surface supports oversized projects and multiple simultaneous jobs.
- 30-tube filtration system provides maximum filtration capacity and airflow consistency.
- Four integrated receptacles improve workstation productivity and convenience.
- Manual filter cleaning system helps minimize maintenance downtime.
- Integrated casters provide mobility and flexible shop layouts.
The Denray 9600 Tube Filtration is one of the largest and most powerful downdraft sanding tables available for woodworking professionals who demand maximum workspace, superior filtration, and industrial-grade performance. Featuring 99% filtration efficiency at 1 micron, 4,300 CFM airflow, thirty tube filters, and a massive 96" × 48" work surface, this system delivers exceptional dust collection performance for large-scale wood dust applications.
