Denray 7200 Tube Filtration Applications
- Large woodworking and sanding operations
- Cabinet and furniture manufacturing facilities
- Architectural millwork production
- High-volume finishing departments
- Large panel, door, and tabletop sanding applications
- Multi-operator sanding workstations
- Custom woodworking and fabrication environments
- Collection of fine airborne wood dust generated during sanding and finishing processes
Ideal for facilities that need a larger sanding surface capable of accommodating multiple projects or operators while maintaining exceptional dust collection performance.
Denray 7200 Tube Filtration Specifications
| Model | 7200 Tube Filtration |
|---|---|
| Work Surface Size | 72" × 48" |
| Overall Height | 36" |
| Weight | 750 lbs |
| Motor | 2 HP |
| Fan Diameter | 16.5" |
| Airflow Capacity | 3,800 CFM |
| Sound Level | 78 dB |
| Filtration System | 25 Tube Filters |
| Filtration Efficiency | 99% Capture Rate at 1 Micron |
| Mobility | Integrated Casters |
| Electrical Receptacles | 3 Receptacles |
| Starter | Magnetic Starter Included |
Denray 7200 Tube Filtration Electrical Requirements
| Configuration | Voltage | Amperage |
|---|---|---|
| Single Phase | 115V | 18.8 Amps |
| Single Phase | 220V | 9.4 Amps |
| Three Phase | 230V | 5.8 Amps |
| Three Phase | 460V | 2.9 Amps |
| Three Phase | 575V | 2.4 Amps |
Denray 7200 Tube Filtration Performance & Construction
- 99% Filtration Efficiency at 1 Micron captures fine airborne wood dust and significantly improves workplace air quality.
- Advanced Tube Filtration Technology provides superior filtration performance compared to traditional pleated filter systems, helping maintain consistent airflow and dust collection efficiency.
- 25 High-Efficiency Tube Filters maximize filtration surface area for exceptional dust capture and extended filter performance.
- Powerful 3,800 CFM Airflow Capacity creates strong downward airflow across the entire work surface to capture dust directly at its source.
- 16.5-Inch Industrial Fan delivers reliable suction and dependable performance for demanding sanding operations.
- Large 72" × 48" Work Surface accommodates oversized projects while providing enough room for multiple operators or simultaneous workpieces.
- Manual Filter Cleaning System includes a filter cleaning brush and handle for quick maintenance and consistent operating performance.
- Rubber-Coated Tabletop protects finished materials from scratches and provides a durable, slip-resistant work surface.
- Magnetic Starter Included provides reliable motor control and enhanced operational safety.
- Heavy-Duty Steel Construction is engineered for continuous industrial use and long-term durability.
- Integrated Casters allow easy mobility and flexible workstation placement throughout the facility.
- Three Built-In Receptacles provide convenient access to power for sanders, tools, and accessories.
Denray 7200 Tube Filtration Available Options
- Explosion Proof Motor (Three-Phase Models Only)
- Light Bar
- Muffler Package (Reduces Sound Levels by Approximately 10–12 dB)
- Three-Sided Hinged Safety Shield
- HDPE Plastic Tabletop Upgrade
- Larger Motor and Fan Upgrade Package
Optional upgrades allow the Denray 7200 Tube Filtration to be customized for specialized applications, increased airflow requirements, enhanced operator protection, and reduced operating noise.
Why Choose the Denray 7200 Tube Filtration
- Designed for larger woodworking projects and multi-operator workstations.
- 99% filtration efficiency at 1 micron for exceptional airborne dust control.
- Advanced tube filtration technology outperforms many traditional pleated filter systems.
- Powerful 3,800 CFM airflow captures dust directly at the source.
- Large 72" × 48" work surface accommodates multiple projects simultaneously.
- 25-tube filtration system provides maximum filtration capacity and airflow consistency.
- Magnetic starter included for reliable operation and enhanced safety.
- Three integrated receptacles improve workstation productivity.
- Mobile design with integrated casters for flexible shop layouts.
The Denray 7200 Tube Filtration is a high-capacity downdraft sanding table built for woodworking facilities that require exceptional dust collection performance, expanded workspace capacity, and superior filtration technology. With 99% filtration efficiency at 1 micron, powerful 3,800 CFM airflow, twenty-five tube filters, and a large multi-user work surface, this system delivers professional-grade dust control for demanding wood dust applications.
