Denray 2800 Tube Filtration Applications
- Wood sanding and finishing operations
- Cabinet manufacturing facilities
- Furniture production shops
- Millwork and architectural woodworking operations
- Custom woodworking and fabrication environments
- Schools, vocational training facilities, and maintenance shops
- Dust control for handheld sanders and manual finishing stations
- Collection of fine airborne wood dust generated during sanding processes
Ideal for wood dust applications requiring high-efficiency filtration and source-capture dust collection directly at the workstation.
Denray 2800 Tube Filtration Specifications
| Model | 2800 Tube Filtration |
|---|---|
| Work Surface Size | 28" × 48" |
| Overall Height | 36" |
| Weight | 400 lbs |
| Motor Options | 1.5 HP (Single Phase) or 2 HP (Three Phase) |
| Fan Diameter | 15" |
| Airflow Capacity | 2,800 CFM |
| Sound Level | 70 dB |
| Filtration System | 9 Tube Filters |
| Filtration Efficiency | 99% Capture Rate at 1 Micron |
| Mobility | Integrated Casters |
| Electrical Receptacle | 1 Receptacle (Single Phase Models) |
Denray 2800 Tube Filtration Electrical Requirements
| Configuration | Voltage | Amperage |
|---|---|---|
| Single Phase | 115V | 18.8 Amps |
| Single Phase | 220V | 9.4 Amps |
| Three Phase | 230V | 5.8 Amps |
| Three Phase | 460V | 2.9 Amps |
| Three Phase | 575V | 2.4 Amps |
Denray 2800 Tube Filtration Performance & Construction
- Advanced Tube Filtration Technology delivers a 99% capture rate at 1 micron, helping remove fine airborne wood dust before it circulates throughout the workspace.
- 2,800 CFM Airflow Capacity provides strong downward air movement across the work surface to efficiently capture sanding dust at its source.
- Nine High-Efficiency Tube Filters create a large filtration surface area for consistent airflow and effective particulate removal.
- Manual Filter Cleaning System includes a built-in filter brush and handle, allowing operators to quickly clean filters and maintain optimal performance.
- Rubber-Coated Work Surface helps protect workpieces from scratches while providing a durable and comfortable sanding surface.
- Heavy-Duty Steel Construction withstands demanding industrial environments while providing long-term structural stability.
- Low 70 dB Operating Sound Level creates a quieter work environment compared to many industrial dust collection systems.
- Integrated Casters allow easy relocation of the unit throughout the shop as production needs change.
- Multiple Voltage Configurations support installation in a wide range of commercial and industrial facilities.
- Compact Footprint provides powerful dust collection performance without consuming excessive floor space.
Denray 2800 Tube Filtration Available Options
- Explosion Proof Motor (Three-Phase Models Only)
- LED Light Bar
- Muffler Package (Reduces Sound Levels by Approximately 10–12 dB)
- Three-Sided Hinged Safety Shield
- HDPE Plastic Tabletop Upgrade
- Larger Motor and Fan Performance Upgrade
Optional upgrades allow the Denray 2800 Tube Filtration to be configured for specialized applications, enhanced operator safety, quieter operation, and increased airflow performance.
Why Choose the Denray 2800 Tube Filtration
- Designed specifically for wood dust collection and sanding applications.
- 99% filtration efficiency at 1 micron for exceptional air quality.
- 2,800 CFM airflow captures dust directly at the source.
- Low 70 dB sound rating promotes a more comfortable work environment.
- Standard manual filter cleaning system reduces maintenance downtime.
- Durable rubber-coated tabletop protects finished workpieces.
- Compact footprint with industrial-grade performance.
- Available in both single-phase and three-phase configurations.
- Mobile design with integrated casters for shop flexibility.
The Denray 2800 Tube Filtration is an ideal downdraft sanding table for woodworking professionals seeking high-efficiency dust collection, reliable performance, and cleaner air throughout their facility. With 99% filtration at 1 micron, powerful 2,800 CFM airflow, and a rugged industrial design, this unit delivers the performance needed for demanding wood sanding operations.
