Applications
- Table saw ripping and straight-line cutting
- Shaper and spindle molder operations
- Router table feeding
- Planer and sander material control
- Production and heavy-duty woodworking environments
Ideal for shops requiring stronger feeding force, multiple speed options, and maximum reliability in continuous use applications.
Specifications
| Model | ST-3 TANK |
|---|---|
| Feeding Speeds (FPM) | 6 – 102 (8 Speeds) |
| Drive System | 10" Belt Drive |
| Motor | 1 HP, 3 Phase, 230 V |
| Roller Suspension | 1" |
| Net Weight | 134 LBS |
| Gross Weight | 147 LBS |
Performance & Construction Features
- Powerful belt-drive transmission provides smooth torque delivery and consistent feeding strength.
- Three feed rollers with individual suspension systems maintain even pressure on varying stock thicknesses.
- Removable center roller allows increased spacing for curve driving applications.
- Eight feeding speeds created using two sets of interchangeable gears for optimal material control.
- Forward and reverse switch for flexible operation.
- Side-feed adjustment capability for spindle molder operations.
- Universal support stand with heavy cast iron base, thick refaced column, and rigid main bracket.
- Aluminum hand wheels allow precise vertical and horizontal positioning.
- Quick assembly, dismantling, and easy adjustment for multi-machine compatibility.
Optional Accessory
- ST-30BT – Extra Base for ST-30 Series: $46.00 each
Add an extra base to quickly transfer the feeder between machines without additional setup time.
Why Choose the Castaly ST-TANK Power Feeder
- Heavy-duty belt drive for smooth, high-torque feeding.
- Wide 8-speed range (6–102 FPM) for versatile applications.
- Durable 1 HP, 3-phase motor built for production environments.
- Improves safety, surface finish quality, and productivity.
- Rigid universal stand ensures long-term stability and precision.
The Castaly ST-TANK Power Feeder delivers industrial-grade performance, powerful feeding control, and long-lasting durability for demanding woodworking operations.
