Castaly 7.5 HP Dust Collector Applications
- Cabinet and furniture manufacturing plants
- Production woodworking shops running multiple machines
- Planers, shapers, wide belt sanders, and large table saw systems
- Central dust collection for multi-station work areas
Best for high-output shops that need higher airflow than 3 HP or 5 HP collectors and want increased bag capacity.
Castaly 7.5 HP Dust Collector Specifications
| Model | DC-8075 |
|---|---|
| Motor | 7-1/2 HP (3 Phase) |
| Fan Diameter | 15-3/4" |
| Static Pressure | 15 |
| Air Capacity | 6,700 CFM |
| Sound Rating | 75 – 90 dB |
| Main Connection | 10" × 1 |
| Secondary Connections | 4" × 8 |
| Bottom Bag Capacity | 48 CUFT |
| Bag Diameter | 23-3/4" |
| Top Bag Length | 59" or 118" |
| Bottom Bag Length | 48" |
| Machine Height | 119" or 178" |
| Net Weight | 617 lbs |
| Gross Weight | 770 lbs |
Castaly 7.5 HP Dust Collector Performance & Construction
- Radial-fin type steel impeller designed for high-efficiency airflow.
- Heavy-duty 7.5 HP motor provides strong suction for high-output shops.
- Four top filter bags and four bottom collection bags for higher filtration area and capacity.
- Larger impeller and extended top filter bags improve sawdust and wood chip collection.
- Steel spring clamps secure the bags to reduce dust leakage.
- Low sound design helps reduce noise in production environments.
- Vehicle casters allow repositioning when needed.
- Optional replacement bags or 5-micron bags available for finer dust filtration.
Why Choose the Castaly 7.5 HP Dust Collector
- 6,700 CFM airflow for high-demand production shops.
- Large 48 CUFT bag capacity for longer run time before disposal.
- Expanded filtration area with 4 top filter bags for better performance.
- High static pressure (15) supports longer duct runs and multiple drops.
- Industrial-grade construction built for daily use.
The Castaly 7.5 HP Dust Collector is a high-output solution for serious woodworking facilities that need strong airflow, big capacity, and dependable long-term dust control.
