Castaly 20 HP DC-9200 Dust Collector Applications
- Cabinet, millwork, and furniture manufacturing plants
- Large production shops running multiple machines on centralized ducted collection
- CNC routers, planers, jointers, shapers, large saw systems, and chip-producing lines
- Wide belt sanders and high-fines processes that require stable airflow and filtration capacity
- Central dust collection zones with multiple branches and continuous operation schedules
Best for facilities needing high-volume airflow with industrial durability to support multi-machine duct systems.
Castaly 20 HP DC-9200 Dust Collector Specifications
| Model | DC-9200 |
|---|---|
| Motor | 20 HP (3 Phase) |
| Fan Diameter | 15" |
| Static Pressure (InH2O) | 27 |
| Air Capacity | 7,500 CFM |
| Sound Rating | 85 – 95 dB |
| Connection Outlet Diameter | 16" |
| Top Filter Bag Size (Dia × H) | 13.8" × 59" |
| Top Filter Bag Quantity | 20 |
| Bottom Collect Bag Size | 23.6" × 35.5" |
| Bottom Collect Bag Quantity | 6 |
| Machine Size | 181" × 47" × 120" |
| Net Weight | 1,770 |
Castaly 20 HP DC-9200 Dust Collector Performance & Construction
- Heavy sheet metal frame and base provide stability under continuous industrial use and resist long-term fatigue in high-demand production environments.
- Extra large radial-fin type steel impeller is designed for high-efficiency airflow, strong capture velocity at machine hoods, and dependable performance through ductwork.
- Heavy duty, totally enclosed industrial motor supports maximum air suction and extended service life by helping protect internal components from dust exposure.
- High static pressure capability (27 InH2O) helps maintain performance in centralized systems with multiple drops, longer duct runs, elbows, blast gates, and higher resistance zones.
- Large filtration surface area using 20 top filter bags helps capture airborne dust while supporting steady airflow during long production shifts.
- High-capacity collection system with 6 bottom collection bags increases debris holding volume and reduces downtime from frequent bag changes.
- Low sound levels help keep the working area quieter for a unit of this output class (rated 85–95 dB, dependent on installation and duct configuration).
For best results, pair the Castaly 20 HP DC-9200 Dust Collector with properly sized main trunk ducting, balanced branch lines, and correctly positioned machine hoods to maximize capture efficiency.
Why Choose the Castaly 20 HP DC-9200 Dust Collector
- 7,500 CFM airflow output for large, high-demand shop environments.
- 27 InH2O static pressure performance to support multi-drop, ducted collection systems.
- Industrial radial-fin impeller and totally enclosed motor for strong suction and long service life.
- High filter and collection capacity designed to handle production dust and chips with reduced interruptions.
- Heavy-duty frame and base for stable operation in industrial settings.
The Castaly 20 HP DC-9200 Dust Collector is a central dust collection solution built for production shops that need high airflow, dependable suction through ductwork, and industrial-grade durability day after day.
