Burr King 2 x 48 Three Wheel Belt Grinder Model 482 41110 Applications
- General-purpose belt grinding for metal fabrication shops.
- Deburring machined components and fabricated parts.
- Surface finishing and blending weld seams.
- Knife, tool, and blade sharpening.
- Edge preparation before welding or coating.
- Removing rust, scale, paint, and oxidation.
- Finishing stainless steel, aluminum, carbon steel, and other metals.
- Maintenance, repair, and production grinding operations.
- Industrial manufacturing, maintenance facilities, vocational schools, and fabrication departments.
Ideal for professionals who require variable-speed belt grinding with excellent control, quick belt changes, and dependable American-made construction.
Burr King 2 x 48 Three Wheel Belt Grinder Model 482 41110 Specifications
| Model | 482 41110 |
|---|---|
| Belt Size | 2" x 48" |
| Motor | 1 HP |
| Voltage / Phase | 120 Volt / Single Phase |
| Frequency | 50–60 Hz |
| Speed Type | Variable Speed |
| Belt Speed | 600–6,000 SFPM |
| Wheel Configuration | Three Wheel Design |
| Contact Wheel Size | 5" × 2" |
| Contact Wheel Hardness | 55 Duro Standard |
| Throat Clearance | 7-1/2" |
| Steel Backup Platen | 2" × 6" × 1/4" |
| Belt Tension System | Quick Change Assembly |
| Belt Tracking | Positive Belt Tracking Adjustment |
| Adjustable Work Rest | Yes |
| Safety Belt Guard | Yes |
| Construction | Cast Aluminum |
| Mounting | Bench or Pedestal Mount |
| Pedestal Included | No |
| Overall Dimensions (H × W × D) | 21" × 20" × 19" |
| Base Area | 10" × 13" |
| Weight | 100 lbs |
| Country of Origin | USA |
| Main Application | Belt Grinding |
Burr King 2 x 48 Three Wheel Belt Grinder Model 482 41110 Performance & Construction
- Powerful 1 HP industrial motor provides dependable performance for continuous grinding, finishing, and deburring operations.
- Variable belt speed from 600 to 6,000 SFPM allows operators to match grinding speed to the material, abrasive, and finishing requirements.
- Three-wheel belt system improves belt accessibility while providing smooth belt travel for precision grinding and contour work.
- Quick-change belt tension assembly minimizes downtime by allowing rapid abrasive belt replacement during production.
- Positive belt tracking adjustment keeps belts centered for improved accuracy, longer belt life, and consistent performance.
- 5" × 2" contact wheel with 55 Duro hardness offers an excellent balance between aggressive stock removal and controlled finishing.
- Heavy-duty cast aluminum construction delivers exceptional rigidity while remaining lightweight and corrosion resistant.
- Integrated steel backup platen provides solid support during flat grinding and finishing operations.
- Adjustable work rest increases operator control for accurate grinding angles and repeatable results.
- Safety belt guard enhances operator protection during everyday grinding operations.
- Compact footprint allows installation on either a workbench or optional pedestal, making it ideal for shops with limited floor space.
- Made in the USA using Burr King's renowned manufacturing quality for dependable long-term industrial service.
Why Choose the Burr King 2 x 48 Three Wheel Belt Grinder Model 482 41110
- Variable speed control from 600–6,000 SFPM for maximum versatility.
- Professional three-wheel design provides excellent belt access and flexibility.
- Quick-change belt system reduces setup and maintenance time.
- Positive tracking adjustment ensures smooth, consistent grinding performance.
- Heavy-duty cast aluminum construction built for industrial durability.
- Compact design fits bench or pedestal mounting applications.
- Ideal for grinding, deburring, blending, finishing, sharpening, and fabrication work.
- Proudly manufactured in the USA for dependable professional performance.
The Burr King 2 x 48 Three Wheel Belt Grinder Model 482 41110 delivers the precision, durability, and versatility demanded by professional fabricators, machine shops, maintenance departments, and industrial manufacturers. Combining variable-speed performance, rugged American-made construction, and Burr King's proven three-wheel grinding design, this machine is built to provide years of reliable belt grinding performance across a wide range of metalworking applications.
