Burr King 2 x 48 Three Wheel Belt Grinder Model 482 40100 Applications
- General-purpose metal grinding and stock removal.
- Deburring machined, stamped, laser-cut, and fabricated components.
- Surface blending, finishing, and weld cleanup.
- Edge beveling and precision contour grinding.
- Tool sharpening and custom fabrication work.
- Grinding steel, stainless steel, aluminum, brass, titanium, and other metals.
- Ideal for fabrication shops, maintenance departments, welding facilities, educational shops, and production environments.
The three-wheel design provides increased belt accessibility and a generous 7-1/2-inch throat clearance, making the grinder ideal for handling larger or more complex workpieces.
Burr King 2 x 48 Three Wheel Belt Grinder Model 482 40100 Specifications
| Model | 482 (40100) |
|---|---|
| Belt Size | 2" × 48" |
| Motor | 1 HP |
| Voltage / Phase | 120 Volt / Single Phase |
| Frequency | 60 Hz |
| Belt Speed | 6,000 SFPM (Fixed Speed) |
| Variable Speed | No |
| Number of Wheels | 3 |
| Contact Wheel Size | 5" × 2" |
| Contact Wheel Hardness | 55 Duro (Standard) |
| Throat Clearance | 7-1/2" |
| Steel Backup Platen | 2" × 6" × 1/4" |
| Belt Tension System | Quick Change Assembly |
| Belt Tracking | Positive Tracking Adjustment |
| Adjustable Work Rest | Yes |
| Safety Belt Guard | Included |
| Construction | Cast Aluminum |
| Mounting Options | Bench or Pedestal Mount |
| Pedestal Included | No |
| Base Area | 10" × 13" |
| Overall Dimensions (H × W × D) | 21" × 20" × 19" |
| Machine Weight | 85 lbs |
| Main Application | Belt Grinding |
| Country of Origin | Made in USA |
Burr King 2 x 48 Three Wheel Belt Grinder Model 482 40100 Features & Performance
- Industrial 1 HP motor delivers reliable power for continuous grinding and finishing applications.
- Fixed 6,000 SFPM belt speed provides efficient stock removal while maintaining excellent control for precision work.
- Three-wheel belt configuration increases belt accessibility and improves versatility for contour grinding and complex part geometries.
- 7-1/2-inch throat clearance provides additional working space for larger workpieces and specialized grinding operations.
- 5-inch × 2-inch contact wheel with 55-durometer hardness offers an excellent balance of material removal and finish quality.
- Quick-change belt tension assembly minimizes downtime by allowing rapid abrasive belt replacement.
- Positive belt tracking adjustment ensures smooth, accurate belt alignment during extended operation.
- Heavy-duty cast aluminum construction provides exceptional rigidity, corrosion resistance, and long service life while minimizing vibration.
- Steel backup platen supports accurate flat grinding and controlled finishing applications.
- Adjustable work rest improves operator control and workpiece stability during grinding operations.
- Integrated safety belt guard enhances operator protection without restricting access to the grinding area.
- Bench or pedestal mounting capability allows the grinder to fit a variety of shop layouts and production environments.
- Designed and manufactured in the USA to meet the demands of industrial metalworking professionals.
Why Choose the Burr King 2 x 48 Three Wheel Belt Grinder Model 482 40100
- Professional-grade three-wheel grinder designed for precision metalworking.
- Compact footprint with generous throat clearance for increased versatility.
- High-performance 6,000 SFPM belt speed for efficient grinding and finishing.
- Quick-change belt system and precision tracking reduce downtime.
- Heavy-duty cast aluminum construction built for years of industrial use.
- Flexible bench or pedestal mounting options to fit virtually any workspace.
- Ideal for fabrication, machining, welding, maintenance, and custom metalworking applications.
- Proudly designed and manufactured in the USA.
The Burr King 2 x 48 Three Wheel Belt Grinder Model 482 40100 combines compact dimensions, rugged industrial construction, and precision grinding performance into one versatile machine. Its three-wheel design, generous throat clearance, and dependable American-made quality make it an outstanding solution for professional grinding, deburring, blending, and finishing operations.
