Burr King 2.5 x 60 Two Wheel Belt Grinder Model 960-250 92110 Applications
- Heavy-duty metal grinding and rapid stock removal.
- Precision deburring of machined and fabricated components.
- Edge beveling, weld blending, and surface preparation.
- Fine finishing, polishing preparation, and surface conditioning.
- Knife making, tool sharpening, and custom fabrication.
- Grinding steel, stainless steel, aluminum, brass, titanium, and exotic alloys.
- Ideal for fabrication shops, maintenance departments, production manufacturing, aerospace, and industrial metalworking operations.
The adjustable belt speed allows operators to optimize grinding performance for different materials, abrasives, and finishing requirements, making this one of Burr King's most versatile industrial belt grinders.
Burr King 2.5 x 60 Two Wheel Belt Grinder Model 960-250 92110 Specifications
| Model | 960-250 (92110) |
|---|---|
| Belt Size | 2.5" × 60" |
| Motor | 1.5 HP |
| Voltage / Phase | 120 Volt / Single Phase |
| Frequency | 50–60 Hz |
| Speed Type | Variable Speed |
| Belt Speed Range | 800–8,000 SFPM |
| Number of Wheels | 2 |
| Contact Wheel Size | 7" × 2.5" |
| Contact Wheel Hardness | 55 Duro (Standard) |
| Throat Clearance | None |
| Steel Backup Platen | 2.5" × 8" |
| Belt Tension System | Quick Change Assembly |
| Belt Tracking | Positive Tracking Adjustment |
| Adjustable Work Rest | Yes |
| Safety Belt Guard | Included |
| Construction | Cast Aluminum |
| Mounting Options | Bench or Pedestal Mount |
| Pedestal Included | No |
| Base Area | 8.5" × 8" |
| Overall Dimensions (H × W × D) | 30" × 21" × 30" |
| Machine Weight | 115 lbs |
| Main Application | Belt Grinding |
| Country of Origin | Made in USA |
Burr King 2.5 x 60 Two Wheel Belt Grinder Model 960-250 92110 Features & Performance
- Industrial 1.5 HP motor provides dependable power for continuous-duty grinding and finishing applications.
- Variable belt speed from 800 to 8,000 SFPM allows precise speed selection for aggressive grinding, precision deburring, blending, polishing preparation, and heat-sensitive materials.
- 2.5" × 60" abrasive belt capacity offers a large grinding surface that improves belt life and productivity.
- 7" × 2.5" contact wheel with 55-durometer hardness delivers an ideal combination of material removal and finish quality.
- Quick-change belt tension assembly enables rapid abrasive belt changes, reducing production downtime.
- Positive belt tracking adjustment maintains accurate belt alignment for smooth, reliable operation.
- Heavy-duty cast aluminum construction minimizes vibration while providing outstanding strength, rigidity, and long-term durability.
- Steel backup platen provides a rigid grinding surface for accurate flat grinding and controlled finishing operations.
- Adjustable work rest improves workpiece support and operator control for greater grinding accuracy.
- Integrated safety belt guard enhances operator protection during high-speed grinding operations.
- Bench or pedestal mounting capability allows installation flexibility for production cells, fabrication shops, and maintenance facilities.
- Proudly manufactured in the USA for dependable industrial performance and long service life.
Why Choose the Burr King 2.5 x 60 Two Wheel Belt Grinder Model 960-250 92110
- Professional variable-speed belt grinder designed for industrial metalworking.
- Wide 800–8,000 SFPM speed range provides exceptional application flexibility.
- Powerful 1.5 HP motor delivers consistent grinding performance.
- Quick-change belt system and precision tracking improve productivity.
- Heavy-duty cast aluminum construction built for years of continuous service.
- Suitable for grinding, deburring, beveling, blending, and surface finishing.
- Flexible bench or pedestal mounting options fit virtually any shop layout.
- Designed and manufactured in the USA for professional industrial reliability.
The Burr King 2.5 x 60 Two Wheel Belt Grinder Model 960-250 92110 combines industrial durability with the versatility of variable-speed operation, allowing operators to optimize grinding performance for virtually any material or finishing application. From aggressive stock removal to precision finishing, this grinder delivers the control, reliability, and performance demanded by today's professional metalworking environments.
