Baileigh Hydraulic Press HSP-60M 1012740A Applications
- Metal fabrication and production facilities
- Bending and forming steel components
- Straightening shafts, plates, and fabricated assemblies
- Bearing installation and removal operations
- Maintenance and repair workshops
- Agricultural equipment servicing
- Industrial machinery rebuilding and restoration
- Press-fit assembly and disassembly procedures
- Custom fabrication and prototype development projects
Ideal for shops requiring dependable hydraulic force, flexible work positioning, and industrial-grade construction for daily production and maintenance tasks.
Baileigh Hydraulic Press HSP-60M 1012740A Specifications
| Model Number | HSP-60M |
|---|---|
| Product Number | 1012740A |
| Maximum Capacity | 60 Tons |
| Motor Power | 5 HP |
| Input Power | 220V, Three Phase |
| Working Width | 41.25" |
| Cylinder Stroke | 11.5" |
| Distance from Table to Ram | 10.04" Minimum – 39.57" Maximum |
| Cylinder Movement | Left-to-Right Adjustable |
| Hydraulic Pump Type | Piston Style |
| Speed | 1440 RPM |
| Frame Construction | Heavy Welded Steel Plate |
| Gross Weight | 2,200 lbs. |
| Net Weight | 2,200 lbs. |
| UPC | 19907676386 |
| Warranty | 1 Year Parts Warranty |
Baileigh Hydraulic Press HSP-60M 1012740A Performance & Construction
- 60-ton hydraulic capacity delivers substantial pressing force for demanding fabrication, maintenance, assembly, and repair applications.
- Heavy-duty welded steel frame construction provides superior rigidity and durability while minimizing flex under load.
- 5 HP industrial motor supplies reliable power to the hydraulic system for consistent performance throughout the workday.
- 220V three-phase operation integrates easily into industrial workshops and manufacturing environments.
- 41.25-inch working width accommodates a wide range of parts, assemblies, and fabrication projects.
- 11.5-inch cylinder stroke provides ample vertical travel for pressing, forming, and straightening operations.
- Movable hydraulic cylinder travels left and right within the frame, allowing convenient off-center pressing without repositioning the workpiece.
- Piston-style hydraulic pump ensures efficient force generation and dependable hydraulic performance.
- Integrated pressure gauge allows operators to monitor applied force and improve process accuracy.
- Included two-piece V-block set provides secure support for round stock, shafts, tubing, and specialized components.
- Industrial H-frame design offers excellent accessibility and versatility for a broad range of workshop applications.
- Lifetime technical support from Baileigh provides long-term assistance and operational confidence for professional users.
Why Choose the Baileigh Hydraulic Press HSP-60M 1012740A
- 60 tons of hydraulic pressing force for heavy-duty industrial applications.
- Heavy welded steel frame engineered for durability and stability.
- Movable cylinder design simplifies off-center pressing operations.
- 41.25-inch working width accommodates a wide variety of workpieces.
- Pressure gauge and V-block set included for enhanced versatility.
- Powered by a dependable 5 HP motor and piston-style hydraulic system.
- Backed by Baileigh's 1-year warranty and lifetime technical support.
The Baileigh Hydraulic Press HSP-60M 1012740A combines industrial-strength construction, precision hydraulic control, and flexible workpiece positioning to deliver dependable performance for fabrication, repair, maintenance, and production environments requiring reliable 60-ton pressing capability.
