Baileigh 72-Inch Box & Pan Brake, 12-Gauge Mild Steel (BB-7212) 1000536 Applications
- HVAC ductwork fabrication and sheet metal forming.
- Custom metal boxes, pans, trays, and enclosures.
- Architectural sheet metal manufacturing.
- Agricultural equipment component fabrication.
- Industrial maintenance and repair shops.
- Automotive, transportation, and trailer manufacturing.
- General fabrication facilities requiring precision bends in heavy-gauge materials.
- Prototype development and low-to-medium production environments.
Ideal for fabrication shops that require the flexibility of removable fingers, heavy-duty construction, and the capability to bend 12 gauge mild steel with professional accuracy.
Baileigh 72-Inch Box & Pan Brake, 12-Gauge Mild Steel (BB-7212) 1000536 Specifications
| Model Number | BB-7212 |
|---|---|
| Product Number | 1000536 |
| Bending Capacity Length | 72 in. (6 ft.) |
| Mild Steel Capacity | 12 Gauge |
| Stainless Steel Capacity | 16 Gauge |
| Maximum Bend Angle | 135° |
| Maximum Box Depth | 6 in. |
| Operation Type | Manual |
| Finger Configuration | 17 Removable Fingers (3" and 6" Sizes) |
| Frame Construction | Fully Welded Heavy-Duty Steel |
| Net Weight | 2,260 lbs. |
| Gross Weight | 2,260 lbs. |
| UPC | 731325393279 |
| Warranty | 1 Year |
Baileigh 72-Inch Box & Pan Brake, 12-Gauge Mild Steel (BB-7212) 1000536 Performance & Construction
- Heavy-duty fully welded steel frame minimizes flexing and deflection during demanding bending operations, ensuring accurate and repeatable results.
- 72-inch bending width allows operators to process full-size sheet metal panels and long workpieces without compromising capacity.
- 12 gauge mild steel bending capacity provides the strength needed for industrial fabrication projects while maintaining precise bend quality.
- 16 gauge stainless steel capability expands material compatibility for a wide range of fabrication applications.
- 17 removable hardened fingers allow quick setup changes for box and pan forming, channels, trays, enclosures, and specialized bends.
- 3-inch and 6-inch finger configurations provide flexibility when creating custom-sized workpieces and complex forms.
- Maximum 135-degree bend angle enables a broad range of forming operations beyond standard right-angle bends.
- 6-inch maximum box depth accommodates deeper fabricated components and larger formed assemblies.
- Adjustable beam positioning allows operators to accommodate different material thicknesses while maintaining proper clamping pressure.
- Counterbalance weight system reduces operator fatigue and improves control during heavy-gauge bending operations.
- Manual operation eliminates electrical requirements, making the machine suitable for virtually any fabrication environment.
- Industrial-grade design delivers long-term reliability for daily use in professional fabrication shops.
- Baileigh support package includes a 1-year parts warranty and lifetime technical support for added confidence and serviceability.
Why Choose the Baileigh 72-Inch Box & Pan Brake, 12-Gauge Mild Steel (BB-7212) 1000536
- Professional-grade 72-inch box and pan brake designed for demanding fabrication work.
- Bends up to 12 gauge mild steel and 16 gauge stainless steel across the full working width.
- 17 removable fingers provide exceptional versatility for box, pan, and channel forming.
- Heavy-duty welded construction delivers outstanding rigidity and bending accuracy.
- Counterbalanced operation reduces effort while improving operator control.
- Manual design requires no electrical power and offers dependable performance in any shop environment.
- Backed by Baileigh's industry-recognized support network and warranty coverage.
The Baileigh 72-Inch Box & Pan Brake, 12-Gauge Mild Steel (BB-7212) 1000536 combines industrial-strength construction, precision bending performance, and versatile finger brake functionality to provide fabrication professionals with a dependable solution for forming heavy-gauge sheet metal, boxes, pans, channels, and custom components.
