Baileigh 5 TON HYDRAULIC SHOP PRESS HSP-5A 1232702 Applications
- Pressing bearings, bushings, and sleeves into assemblies.
- Straightening bent metal components and fabricated parts.
- Light-duty forming and shaping of steel, aluminum, and other materials.
- Assembly and disassembly of mechanical components.
- Maintenance and repair shop operations.
- Fabrication projects requiring controlled pressing force.
- General workshop and industrial service applications.
The compact footprint and adjustable work table make the HSP-5A an excellent choice for shops that need dependable hydraulic pressing performance without sacrificing valuable floor space.
Baileigh 5 TON HYDRAULIC SHOP PRESS HSP-5A 1232702 Specifications
| Model Number | HSP-5A |
|---|---|
| Product Name | Baileigh 5 TON HYDRAULIC SHOP PRESS HSP-5A 1232702 |
| Press Capacity | 5 Tons |
| Frame Style | H-Frame |
| Working Width | 19.5" |
| Stroke Length | 4" |
| Operation Type | Manual Hydraulic |
| Input Power | Manual |
| Hydraulic System | Industrial-Grade Hydraulic Components |
| Adjustable Work Table | Multiple Height Positions |
| Net Weight | 201 lbs |
| Gross Weight | 201 lbs |
| Rating | 5 Tons |
| UPC | 19907201137 |
| Warranty | 1 Year |
Baileigh 5 TON HYDRAULIC SHOP PRESS HSP-5A 1232702 Performance & Construction
- 5-Ton Hydraulic Capacity: Provides ample force for light-duty pressing, forming, straightening, and assembly applications.
- Rigid Welded H-Frame: Heavy-duty steel frame construction delivers excellent structural strength and long-term durability.
- 19.5" Working Width: Offers ample clearance between uprights for a wide range of component sizes and shop tasks.
- 4" Stroke Length: Allows controlled pressing travel for accurate and repeatable operation.
- Industrial Hydraulic Components: Designed for smooth force application and dependable long-term performance.
- Adjustable Work Table: Multiple positioning options provide flexibility when working with different part sizes and tooling setups.
- Compact Shop Footprint: Maximizes functionality while minimizing floor space requirements.
- Manual Hydraulic Operation: Simple and reliable design reduces maintenance requirements and operating complexity.
- Versatile Workshop Tool: Suitable for pressing bearings, straightening parts, bending materials, and general repair operations.
- Heavy-Duty Construction: The 201 lb machine weight contributes to stability and rigidity during pressing operations.
Why Choose the Baileigh 5 TON HYDRAULIC SHOP PRESS HSP-5A 1232702
- 5-ton hydraulic force handles a wide variety of light-duty shop tasks.
- Compact H-frame design fits efficiently into smaller workspaces.
- 19.5" working width accommodates many common fabrication and repair projects.
- 4" stroke provides controlled pressing action and versatility.
- Adjustable work table simplifies setup for different part sizes.
- Durable welded steel construction ensures long service life.
- Ideal for maintenance departments, fabrication shops, and industrial workshops.
- Backed by Baileigh's 1-year warranty and lifetime technical support.
The Baileigh 5 TON HYDRAULIC SHOP PRESS HSP-5A 1232702 combines compact dimensions, dependable hydraulic performance, and rugged welded-steel construction into a versatile pressing solution for professionals who require reliable force, flexibility, and durability in everyday shop operations.
